Satellite Frequencies

Details for a specific satellite can be found at the end of the frequency descriptions.

Downloadable Satellite Frequencies for Meteorological and Earth Observation Satellites, Updated 03-01-2023

List of Satellite Frequencies by Band

VHF Band

• 136 – 138 MHz:  This band was used heavily by many different types of satellites in the past. Today (2023), most activity is restricted to 137-138 MHz (which is the current allocation) and consists of meteorological satellites transmitting data and low-resolution images, together with low data rate mobile satellite downlinks (eg Orbcomm)
• 144 – 146 MHz:  One of the most popular bands for amateur satellite activity. Most of the links are found in the upper half of the band (145 – 146 MHz).
• 148 – 150 MHz:  This tends to be used for uplinks of the satellites that downlink in the 137 – 138 MHz band.
• 149.95 – 150.05 MHz:  This is used by satellites providing positioning, time and frequency services, by ionospheric research and other satellites. Before the advent of GPS it was home to large constellations of US and Russian satellites that provided positioning information (mainly to marine vessels) by use of the Doppler effect). Many satellites transmitting on this band also transmit a signal on 400 MHz.
• 240 – 270 MHz:  Military satellites, communications. This band lies in the wider frequency allocation (225 – 380 MHz) assigned for military aviation.

UHF Band

• 399.9 – 403 MHz:  This band includes navigation, positioning, time and frequency standard, mobile communication, and meteorological satellites. Around 400 MHz is a companion band for satellites transmitting on 150 MHz.
• 432 – 438 MHz:  This range includes a popular amateur satellite band as well as a few Earth resources satellites.
• 460 – 470 MHz:  Meteorological and environmental satellites, including uplink frequencies for remote environmental data sensors.

L Band

• 1.2 – 1.8 GHz: This frequency range includes a very diverse range of satellites and encompasses many sub-allocations. This range includes the GPS and other GNSS (Global Navigation Satellite Systems – Russian Glonass, European Galileo, Chinese Beidou). It also hosts SARSAT/COSPAS search and rescue satellites which are carried on board US and Russian meteorological satellites. It also includes a mobile satellite communication band.
• 1.67 – 1.71 GHz:  This is one of the primary bands for high-resolution meteorological satellite downlinks of data and imagery.

S Band

• 2.025 – 2.3 GHz: Space operations and research, including ‘deep space’ links from beyond Earth orbit. This encompasses the Unified S-band (USB) plan which is used by many spacecraft, and which was also used by the Apollo lunar missions. It also includes military space links including the US Defense Meteorological Satellite Program (DMSP F17/18 ). Many Earth resources (remote sensing) satellites downlink in this band. NOAA 15 GAC (Global Area Coverage) which contains reduced resolution images of all the instruments covering the entirety of the previous orbit. Coriolis is a Defense Dept. Satellite technology demonstration mission
• 2.5 – 2.67 GHz: Fixed (point-to-point) communication and broadcast satellites, although the broadcast allocation is only used in some Asian and Middle-eastern countries.

C Band

• 3.4 – 4.2 GHz:  Fixed satellite service (FSS) and broadcast satellite service (BSS) downlinks. International TV broadcast uses this allocation heavily.
• 5.9 – 6.4 GHz: This is the FSS/BSS uplink for the 3.4-4.2 GHz downlink band.

X band

• 8 – 9 GHz:  This is used heavily for space research, deep space operations, environmental and military communication satellites. Many satellites/spacecraft carry complementary S and X band transmitters.

Ku band

• 10.7 – 11.7 GHz: Fixed satellite services (FSS)
• 11.7 – 12.2 GHz: Broadcast satellite service (BSS) downlinks. This band is used for domestic TV programs.
• 14.5 – 14.8 GHz: The uplink for the previous Ku downlink band.
• 17.3 – 18.1 GHz:  An alternate ‘Ku’ band BSS uplink.

‘Ka’ band

• 23 – 27 GHz: A region that will be used increasingly by a variety of fixed link, broadcast, environmental and space operations satellites in the future as more bandwidth is required than can be provided in the lower bands. The disadvantage of this band is the increased absorption due to water vapour and rain. Not very useful for tropical regions of the Earth.

---

USRadioguy Frequency Allocation List June 30,2023

CURRENT SATS IN THE 137 MHz Range

Name	Catalog Number	COSPAR ID	Frequency MHz	Modulation
ORBCOMM 116 sats currently in orbit	various	various	137.2
			137.225
			137.25
			137.2875
			137.315	SDPSK
			137.44
			137.46
			137.6625
			137.6875
			137.7125
			137.7375
			137.8
			137.910
			137.56	OQPSK
NOAA 15	25338	1998-30A	137.35	PCM/PM
			137.62	AM/FM
NOAA 18	28654	2005-18A	137.35	PCM/PM
			137.9125	AM/FM
NOAA 19	33591	2009-05A	137.77	PCM/PM
			137.1	AM/FM
	numerous	numerous	137.05
SpaceBEE 179 Sats in Orbit			137.845	SS-FM LoRa
			137.975
Starlink	numerous	numerous	137.055	SS-FM LoRa
Meteor-M N2-3	57166	2023-91A	137.9	OQPSK
Meteor-M N2-3	57166	2023-91A	137.1	OQPSK
VLD2	-	-	136.975
SpaceX (Starlink spacecraft) acquired Swarm Technologies (SpacceBEE spacecraft) in 2021 and has now added VHF LoRa protocol beacons to their Starlink spacecraft to provide specialized telemetry, tracking and command functions during launch and early operations phase, orbit raising and emergency operations.
Meteor-M N2-3 launched 1134 UTC 27 June 2023.
Rate ½, k = 7 Convolution coded, I = G1, Q = G2, Power I:Q = 1:1, 144 kilosymbols per second.
CCSDS Format. SCID 00, VCID 05 with 3 out of APIDs 64 to 69, (MSU-MR channels 1 to 6) or VCID 63, Fill
72 kbps OQPSK, 3 vis IR channels, APIDs 64, 65 & 66

---

Satellite Frequencies for Earth Observation, data transfer, platform communications, and control

This table shows all known past, current, and future satellites for meteorological and earth observation purposes. It can be downloaded as a PDF or as a sortable Excel Spreadsheet, or a (It can be sorted by clicking on the column headers.)

Satellite Frequencies Excel Spreadsheet
Satellite Frequencies PDF

Frequencies of transmitting satellites in the 136-138 MHz range.

Name	NORAD Catalog Number	COSPAR ID	Frequency MHz	Modulation
TRANSIT	965	1964-83D	136.653	FM/PM
SOLRAD 7B	1291	1965-16D	136.8	FM/AM
ALOUETTE 2	1804	1965-98A	136.98	Carrier only
ERS 15	2411	1966-77B	136.44	Carrier only
ERS 20	2768	1967-40D	136.26	PM
ISIS 1	3669	1969-9A	136.41	Carrier only
S69-4	4237	1969-82E	137.41	Carrier only
SHINSEI	5485	1971-80A	136.695	Carrier only
NOSS	5680	1971-110C	137.08	Carrier only
NOAA 9	15427	1984-123A	136.77	Carrier only
ECS 4	18351	1987-78B	137.139	PCM/FSK/PM
ECS 5	19331	1988-63B	137.142	PCM/FSK/PM
OXP-1	22491	1993-09C	137.05	PCM/PSK
ORBCOMM	Many different TLE's Check Celestrack.org	Many different TLE's Check Celestrack.org	137.2000 137.2250 137.2500 137.2875 137.3150 137.4400 137.4600 137.5600 137.6625 137.6875 137.7125 137.7375 137.8000	SDPSK SDPSK SDPSK SDPSK SDPSK SDPSK SDPSK OQPSK SDPSK SDPSK SDPSK SDPSK SDPSK
NOAA 15	25338	1998-30A	137.35 137.62	PCM/PM AM/FM
NOAA 18	28654	2005-18A	137.35 137.9125	PCM/PM AM/FM
NOAA 19	33591	2009-05A	137.77 137.10	PCM/PM AM/FM
SpaceBEE 55, 63 and 141 to 179	Many different TLE's Check Celestrack.org	Many different TLE's Check Celestrack.org	137.050 137.250 137.845 137.975	SS-FM LoRa
Starlink	Many different TLE's Check Celestrack.org	Many different TLE's Check Celestrack.org	137.055	SS-FM LoRa
Meteor-M N2-3	57166	2023-91A	137.9	OQPSK
Meteor-M N2-4	59051	2024-39A	137.1	OQPSK
VLD2	-	-	136.975	D8PSK

---

List of all known past, current, and future satellites for meteorological and earth observation purposes as of 03/2023 (same as above downloadable data)

Shows first 500 out 848 satellites

SATELLITE FREQUENCIES FOR EARTH OBSERVATION, DATA TRANSFER, PLATFORM COMMUNICATIONS, AND CONTROL

Satellite	Space Agency	Launch	End Of Life	Service	Direction	Frequency (MHz)	Bandwidth (kHz)	Polarisation	Data rate	Dead/Active	Comment
COMS	KMA	2010-06-26	2021-04-01	CDAS	S-E	1687 MHz	6000 kHz	linear	6000 kBit/s	D	Raw data
COMS	KMA	2010-06-26	2021-04-01	HRIT	E-S	2040.9 MHz	5200 kHz	RHCP	3000 kBit/s	D	High resolution data
COMS	KMA	2010-06-26	2021-04-01	HRIT	S-E	1695.4 MHz	5200 kHz	linear	3000 kBit/s	D	High resolution data
COMS	KMA	2010-06-26	2021-04-01	LRIT	E-S	2037.64 MHz	1000 kHz	RHCP	512 kBit/s	D	Selected data
COMS	KMA	2010-06-26	2021-04-01	LRIT	S-E	1692.14 MHz	1000 kHz	linear	512 kBit/s	D	Selected data
COSMIC-1	NSPO	2006-04-14	2020-05-06	TM & Raw Data	S-E	2215 MHz	4560 kHz	RHCP	2000 kBit/s	D	Telemetry, sensor data
COSMIC-1	NSPO	2006-04-14	2020-05-06	TM & Raw Data	S-E	2215 MHz	64 kHz	RHCP	36.48 kBit/s	D	Telemetry, sensor data
COSMIC-2	NSPO	2019-06-25	≥2026	TM & Raw Data	S-E	2264 MHz	4000 kHz	RHCP	2048 kBit/s	D	Telemetry, sensor data
COSMIC-2	NSPO	2019-06-25	≥2026	TM & Raw Data	S-E	2264 MHz	64 kHz	RHCP	36.48 kBit/s	D	Telemetry, sensor data
COSMIC-2b	NSPO	TBD	TBD	TM & Raw Data	S-E	2264 MHz	2000 kHz	RHCP		D	Telemetry, sensor data
COSMIC-2b	NSPO	TBD	TBD	TM & Raw Data	S-E	2264 MHz	32 kHz	RHCP		D	Telemetry, sensor data
DSCOVR	NOAA	2015-02-11	≥2026	TM & Raw Data	S-E	2215 MHz	1150 kHz	linear	120 kBit/s	D	Telemetry and raw data
Electro-L N1	RosHydroMet	2011-01-20	2016	RDAS	S-E	7500 MHz	73000 kHz	RHCP	2560 kBit/s	D	Raw data
Electro-L N1	RosHydroMet	2011-01-20	2016	RDAS	S-E	7500 MHz	73000 kHz	RHCP	15360 kBit/s	D	Raw data
Electro-L N1	RosHydroMet	2011-01-20	2016	RDAS	S-E	7500 MHz	73000 kHz	RHCP	30720 kBit/s	D	Raw data
Electro-L N1	RosHydroMet	2011-01-20	2016	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	64 kBit/s	D	Processed images and information
Electro-L N1	RosHydroMet	2011-01-20	2016	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	128 kBit/s	D	Processed images and information
Electro-L N1	RosHydroMet	2011-01-20	2016	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	665.4 kBit/s	D	Processed images and information
Electro-L N1	RosHydroMet	2011-01-20	2016	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	1000 kBit/s	D	Processed images and information
Electro-L N1	RosHydroMet	2011-01-20	2016	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	2560 kBit/s	D	Processed images and information
Electro-L N1	RosHydroMet	2011-01-20	2016	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	15360 kBit/s	D	Processed images and information
Electro-L N1	RosHydroMet	2011-01-20	2016	HRIT	S-E	1691 MHz	2000 kHz	RHCP	665.4 kBit/s	D	High resolution data and information
Electro-L N1	RosHydroMet	2011-01-20	2016	HRIT	S-E	1693 MHz	2000 kHz	RHCP	665.4 kBit/s	D	High resolution data and information
Electro-L N1	RosHydroMet	2011-01-20	2016	HRIT	S-E	1691 MHz	2000 kHz	RHCP	1000 kBit/s	D	High resolution data and information
Electro-L N1	RosHydroMet	2011-01-20	2016	HRIT	S-E	1693 MHz	2000 kHz	RHCP	1000 kBit/s	D	High resolution data and information
Electro-L N1	RosHydroMet	2011-01-20	2016	LRIT	S-E	1691 MHz	200 kHz	RHCP	64 kBit/s	D	Low resolution data and information
Electro-L N1	RosHydroMet	2011-01-20	2016	LRIT	S-E	1691 MHz	200 kHz	RHCP	128 kBit/s	D	Low resolution data and information
Electro-L N1	RosHydroMet	2011-01-20	2016	DCS	E-S	401.5 - 402.5 MHz	3 kHz	RHCP	1200 kBit/s	D	Regional & International DCP reports
Electro-L N1	RosHydroMet	2011-01-20	2016	DCS	E-S	401.5 - 402.5 MHz	3 kHz	RHCP	0.400 kBit/s	D	Regional & International DCP reports
Electro-L N1	RosHydroMet	2011-01-20	2016	DCS	E-S	401.5 - 402.5 MHz	3 kHz	RHCP	0.100 kBit/s	D	Regional & International DCP reports
Electro-L N1	RosHydroMet	2011-01-20	2016	DCSA	S-E	1696.4 MHz	2000 kHz	linear	1.200 kBit/s	D	DCP report relay
Electro-L N1	RosHydroMet	2011-01-20	2016	DCSA	S-E	1697 MHz	2000 kHz	linear	1.200 kBit/s	D	DCP report relay
Electro-L N1	RosHydroMet	2011-01-20	2016	DCSA	S-E	1696.4 MHz	400 kHz	linear	0.100 kBit/s	D	DCP report relay
Electro-L N1	RosHydroMet	2011-01-20	2016	DCSA	S-E	1697 MHz	400 kHz	linear	0.100 kBit/s	D	DCP report relay
Electro-L N2	RosHydroMet	2015-12-11	≥2025	RDAS	S-E	7500 MHz	73000 kHz	RHCP	2560 kBit/s	D	Raw data
Electro-L N2	RosHydroMet	2015-12-11	≥2025	RDAS	S-E	7500 MHz	73000 kHz	RHCP	15360 kBit/s	D	Raw data
Electro-L N2	RosHydroMet	2015-12-11	≥2025	RDAS	S-E	7500 MHz	73000 kHz	RHCP	30720 kBit/s	D	Raw data
Electro-L N2	RosHydroMet	2015-12-11	≥2025	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	64 kBit/s	D	Processed images and information
Electro-L N2	RosHydroMet	2015-12-11	≥2025	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	128 kBit/s	D	Processed images and information
Electro-L N2	RosHydroMet	2015-12-11	≥2025	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	665.4 kBit/s	D	Processed images and information
Electro-L N2	RosHydroMet	2015-12-11	≥2025	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	1000 kBit/s	D	Processed images and information
Electro-L N2	RosHydroMet	2015-12-11	≥2025	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	2560 kBit/s	D	Processed images and information
Electro-L N2	RosHydroMet	2015-12-11	≥2025	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	15360 kBit/s	D	Processed images and information
Electro-L N2	RosHydroMet	2015-12-11	≥2025	HRIT	S-E	1691 MHz	2000 kHz	RHCP	665.4 kBit/s	D	High resolution data and information
Electro-L N2	RosHydroMet	2015-12-11	≥2025	HRIT	S-E	1693 MHz	2000 kHz	RHCP	665.4 kBit/s	D	High resolution data and information
Electro-L N2	RosHydroMet	2015-12-11	≥2025	HRIT	S-E	1691 MHz	2000 kHz	RHCP	1000 kBit/s	D	High resolution data and information
Electro-L N2	RosHydroMet	2015-12-11	≥2025	HRIT	S-E	1693 MHz	2000 kHz	RHCP	1000 kBit/s	D	High resolution data and information
Electro-L N2	RosHydroMet	2015-12-11	≥2025	LRIT	S-E	1691 MHz	200 kHz	RHCP	64 kBit/s	D	Low resolution data and information
Electro-L N2	RosHydroMet	2015-12-11	≥2025	LRIT	S-E	1691 MHz	200 kHz	RHCP	128 kBit/s	D	Low resolution data and information
Electro-L N2	RosHydroMet	2015-12-11	≥2025	DCS	E-S	401.5 - 402.5 MHz	3 kHz	RHCP	1.200 kBit/s	D	Regional & International DCP reports
Electro-L N2	RosHydroMet	2015-12-11	≥2025	DCS	E-S	401.5 - 402.5 MHz	3 kHz	RHCP	0.400 kBit/s	D	Regional & International DCP reports
Electro-L N2	RosHydroMet	2015-12-11	≥2025	DCS	E-S	401.5 - 402.5 MHz	3 kHz	RHCP	0.100 kBit/s	D	Regional & International DCP reports
Electro-L N2	RosHydroMet	2015-12-11	≥2025	DCSA	S-E	1696.4 MHz	2000 kHz	linear	1.200 kBit/s	D	DCP report relay
Electro-L N2	RosHydroMet	2015-12-11	≥2025	DCSA	S-E	1697 MHz	2000 kHz	linear	1.200 kBit/s	D	DCP report relay
Electro-L N2	RosHydroMet	2015-12-11	≥2025	DCSA	S-E	1696.4 MHz	400 kHz	linear	0.100 kBit/s	D	DCP report relay
Electro-L N2	RosHydroMet	2015-12-11	≥2025	DCSA	S-E	1697 MHz	400 kHz	linear	0.100 kBit/s	D	DCP report relay
Electro-L N3	RosHydroMet	2019-12-24	≥2029	RDAS	S-E	7500 MHz	73000 kHz	RHCP	2560 kBit/s	D	Raw data
Electro-L N3	RosHydroMet	2019-12-24	≥2029	RDAS	S-E	7500 MHz	73000 kHz	RHCP	15360 kBit/s	D	Raw data
Electro-L N3	RosHydroMet	2019-12-24	≥2029	RDAS	S-E	7500 MHz	73000 kHz	RHCP	30720 kBit/s	D	Raw data
Electro-L N3	RosHydroMet	2019-12-24	≥2029	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	64 kBit/s	D	Processed images and information
Electro-L N3	RosHydroMet	2019-12-24	≥2029	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	128 kBit/s	D	Processed images and information
Electro-L N3	RosHydroMet	2019-12-24	≥2029	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	665.4 kBit/s	D	Processed images and information
Electro-L N3	RosHydroMet	2019-12-24	≥2029	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	1000 kBit/s	D	Processed images and information
Electro-L N3	RosHydroMet	2019-12-24	≥2029	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	2560 kBit/s	D	Processed images and information
Electro-L N3	RosHydroMet	2019-12-24	≥2029	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	15360 kBit/s	D	Processed images and information
Electro-L N3	RosHydroMet	2019-12-24	≥2029	HRIT	S-E	1691 MHz	2000 kHz	RHCP	665.4 kBit/s	D	High resolution data and information
Electro-L N3	RosHydroMet	2019-12-24	≥2029	HRIT	S-E	1693 MHz	2000 kHz	RHCP	665.4 kBit/s	D	High resolution data and information
Electro-L N3	RosHydroMet	2019-12-24	≥2029	HRIT	S-E	1691 MHz	2000 kHz	RHCP	1000 kBit/s	D	High resolution data and information
Electro-L N3	RosHydroMet	2019-12-24	≥2029	HRIT	S-E	1693 MHz	2000 kHz	RHCP	1000 kBit/s	D	High resolution data and information
Electro-L N3	RosHydroMet	2019-12-24	≥2029	LRIT	S-E	1691 MHz	200 kHz	RHCP	64 kBit/s	D	Low resolution data and information
Electro-L N3	RosHydroMet	2019-12-24	≥2029	LRIT	S-E	1691 MHz	200 kHz	RHCP	128 kBit/s	D	Low resolution data and information
Electro-L N3	RosHydroMet	2019-12-24	≥2029	DCS	E-S	401.5 - 402.5 MHz	3 kHz	RHCP	1.200 kBit/s	D	Regional & International DCP reports
Electro-L N3	RosHydroMet	2019-12-24	≥2029	DCS	E-S	401.5 - 402.5 MHz	3 kHz	RHCP	0.400 kBit/s	D	Regional & International DCP reports
Electro-L N3	RosHydroMet	2019-12-24	≥2029	DCS	E-S	401.5 - 402.5 MHz	3 kHz	RHCP	0.100 kBit/s	D	Regional & International DCP reports
Electro-L N3	RosHydroMet	2019-12-24	≥2029	DCSA	S-E	1696.4 MHz	2000 kHz	linear	1.200 kBit/s	D	DCP report relay
Electro-L N3	RosHydroMet	2019-12-24	≥2029	DCSA	S-E	1697 MHz	2000 kHz	linear	1.200 kBit/s	D	DCP report relay
Electro-L N3	RosHydroMet	2019-12-24	≥2029	DCSA	S-E	1696.4 MHz	400 kHz	linear	0.100 kBit/s	D	DCP report relay
Electro-L N3	RosHydroMet	2019-12-24	≥2029	DCSA	S-E	1697 MHz	400 kHz	linear	0.100 kBit/s	D	DCP report relay
Electro-L N4	RosHydroMet	≥2023	≥2033	RDAS	S-E	7500 MHz	73000 kHz	RHCP	2560 kBit/s	D	Raw data
Electro-L N4	RosHydroMet	≥2023	≥2033	RDAS	S-E	7500 MHz	73000 kHz	RHCP	15360 kBit/s	D	Raw data
Electro-L N4	RosHydroMet	≥2023	≥2033	RDAS	S-E	7500 MHz	73000 kHz	RHCP	30720 kBit/s	D	Raw data
Electro-L N4	RosHydroMet	≥2023	≥2033	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	64 kBit/s	D	Processed images and information
Electro-L N4	RosHydroMet	≥2023	≥2033	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	128 kBit/s	D	Processed images and information
Electro-L N4	RosHydroMet	≥2023	≥2033	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	665.4 kBit/s	D	Processed images and information
Electro-L N4	RosHydroMet	≥2023	≥2033	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	1000 kBit/s	D	Processed images and information
Electro-L N4	RosHydroMet	≥2023	≥2033	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	2560 kBit/s	D	Processed images and information
Electro-L N4	RosHydroMet	≥2023	≥2033	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	15360 kBit/s	D	Processed images and information
Electro-L N4	RosHydroMet	≥2023	≥2033	HRIT	S-E	1691 MHz	2000 kHz	RHCP	665.4 kBit/s	D	High resolution data and information
Electro-L N4	RosHydroMet	≥2023	≥2033	HRIT	S-E	1693 MHz	2000 kHz	RHCP	665.4 kBit/s	D	High resolution data and information
Electro-L N4	RosHydroMet	≥2023	≥2033	HRIT	S-E	1691 MHz	2000 kHz	RHCP	1000 kBit/s	D	High resolution data and information
Electro-L N4	RosHydroMet	≥2023	≥2033	HRIT	S-E	1693 MHz	2000 kHz	RHCP	1000 kBit/s	D	High resolution data and information
Electro-L N4	RosHydroMet	≥2023	≥2033	LRIT	S-E	1691 MHz	200 kHz	RHCP	64 kBit/s	D	Low resolution data and information
Electro-L N4	RosHydroMet	≥2023	≥2033	LRIT	S-E	1691 MHz	200 kHz	RHCP	128 kBit/s	D	Low resolution data and information
Electro-L N4	RosHydroMet	≥2023	≥2033	DCS	E-S	401.5 - 402.5 MHz	3 kHz	RHCP	1.200 kBit/s	D	Regional & International DCP reports
Electro-L N4	RosHydroMet	≥2023	≥2033	DCS	E-S	401.5 - 402.5 MHz	3 kHz	RHCP	0.400 kBit/s	D	Regional & International DCP reports
Electro-L N4	RosHydroMet	≥2023	≥2033	DCS	E-S	401.5 - 402.5 MHz	3 kHz	RHCP	0.100 kBit/s	D	Regional & International DCP reports
Electro-L N4	RosHydroMet	≥2023	≥2033	DCSA	S-E	1696.4 MHz	2000 kHz	linear	1.200 kBit/s	D	DCP report relay
Electro-L N4	RosHydroMet	≥2023	≥2033	DCSA	S-E	1697 MHz	2000 kHz	linear	1.200 kBit/s	D	DCP report relay
Electro-L N4	RosHydroMet	≥2023	≥2033	DCSA	S-E	1696.4 MHz	400 kHz	linear	0.100 kBit/s	D	DCP report relay
Electro-L N4	RosHydroMet	≥2023	≥2033	DCSA	S-E	1697 MHz	400 kHz	linear	0.100 kBit/s	D	DCP report relay
Electro-L N5	RosHydroMet	≥2023	≥2033	RDAS	S-E	7500 MHz	73000 kHz	RHCP	2560 kBit/s	D	Raw data
Electro-L N5	RosHydroMet	≥2023	≥2033	RDAS	S-E	7500 MHz	73000 kHz	RHCP	15360 kBit/s	D	Raw data
Electro-L N5	RosHydroMet	≥2023	≥2033	RDAS	S-E	7500 MHz	73000 kHz	RHCP	30720 kBit/s	D	Raw data
Electro-L N5	RosHydroMet	≥2023	≥2033	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	64 kBit/s	D	Processed images and information
Electro-L N5	RosHydroMet	≥2023	≥2033	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	128 kBit/s	D	Processed images and information
Electro-L N5	RosHydroMet	≥2023	≥2033	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	665.4 kBit/s	D	Processed images and information
Electro-L N5	RosHydroMet	≥2023	≥2033	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	1000 kBit/s	D	Processed images and information
Electro-L N5	RosHydroMet	≥2023	≥2033	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	2560 kBit/s	D	Processed images and information
Electro-L N5	RosHydroMet	≥2023	≥2033	HRIT/LRIT/MLTP	E-S	8195 MHz	32000 kHz	LHCP	15360 kBit/s	D	Processed images and information
Electro-L N5	RosHydroMet	≥2023	≥2033	HRIT	S-E	1691 MHz	2000 kHz	RHCP	665.4 kBit/s	D	High resolution data and information
Electro-L N5	RosHydroMet	≥2023	≥2033	HRIT	S-E	1693 MHz	2000 kHz	RHCP	665.4 kBit/s	D	High resolution data and information
Electro-L N5	RosHydroMet	≥2023	≥2033	HRIT	S-E	1691 MHz	2000 kHz	RHCP	1000 kBit/s	D	High resolution data and information
Electro-L N5	RosHydroMet	≥2023	≥2033	HRIT	S-E	1693 MHz	2000 kHz	RHCP	1000 kBit/s	D	High resolution data and information
Electro-L N5	RosHydroMet	≥2023	≥2033	LRIT	S-E	1691 MHz	200 kHz	RHCP	64 kBit/s	D	Low resolution data and information
Electro-L N5	RosHydroMet	≥2023	≥2033	LRIT	S-E	1691 MHz	200 kHz	RHCP	128 kBit/s	D	Low resolution data and information
Electro-L N5	RosHydroMet	≥2023	≥2033	DCS	E-S	401.5 - 402.5 MHz	3 kHz	RHCP	1.200 kBit/s	D	Regional & International DCP reports
Electro-L N5	RosHydroMet	≥2023	≥2033	DCS	E-S	401.5 - 402.5 MHz	3 kHz	RHCP	0.400 kBit/s	D	Regional & International DCP reports
Electro-L N5	RosHydroMet	≥2023	≥2033	DCS	E-S	401.5 - 402.5 MHz	3 kHz	RHCP	0.100 kBit/s	D	Regional & International DCP reports
Electro-L N5	RosHydroMet	≥2023	≥2033	DCSA	S-E	1696.4 MHz	2000 kHz	linear	1.200 kBit/s	D	DCP report relay
Electro-L N5	RosHydroMet	≥2023	≥2033	DCSA	S-E	1697 MHz	2000 kHz	linear	1.200 kBit/s	D	DCP report relay
Electro-L N5	RosHydroMet	≥2023	≥2033	DCSA	S-E	1696.4 MHz	400 kHz	linear	0.100 kBit/s	D	DCP report relay
Electro-L N5	RosHydroMet	≥2023	≥2033	DCSA	S-E	1697 MHz	400 kHz	linear	0.100 kBit/s	D	DCP report relay
FY-2A	CMA	1997-06-10	1998-04-08	CDAS	S-E	1681.6 MHz	20000 kHz	linear	14000 kBit/s	D	Raw data
FY-2A	CMA	1997-06-10	1998-04-08	S-VISSR	E-S	2047.5 MHz	2000 kHz	linear	660 kBit/s	D	High-resolution data
FY-2A	CMA	1997-06-10	1998-04-08	S-VISSR	S-E	1687.5 MHz	2000 kHz	linear	660 kBit/s	D	High-resolution data
FY-2A	CMA	1997-06-10	1998-04-08	WEFAX	E-S	2051 MHz	260 kHz	linear	1.7 kHz	A	Selected data
FY-2A	CMA	1997-06-10	1998-04-08	WEFAX	S-E	1691 MHz	260 kHz	linear	1.7 kHz	A	Selected data
FY-2A	CMA	1997-06-10	1998-04-08	DCP	E-S	401.1 - 401.4 MHz	3 kHz	RHCP	0.600 kBit/s	D	Regional DCP reports
FY-2A	CMA	1997-06-10	1998-04-08	DCP	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports
FY-2A	CMA	1997-06-10	1998-04-08	Ranging	E-S	2050.5 MHz	1000 kHz	linear	500 kBit/s	D	Primary station
FY-2A	CMA	1997-06-10	1998-04-08	Ranging	S-E	1690.5 MHz	1000 kHz	linear	500 kBit/s	D	Primary station
FY-2A	CMA	1997-06-10	1998-04-08	Ranging	E-S	2046.5 MHz	1000 kHz	linear	500 kBit/s	D	Secondary station
FY-2A	CMA	1997-06-10	1998-04-08	Ranging	S-E	1686.5 MHz	1000 kHz	linear	500 kBit/s	D	Secondary station
FY-2A	CMA	1997-06-10	1998-04-08	Ranging	E-S	2044.5 MHz	1000 kHz	linear	500 kBit/s	D	Backup station
FY-2A	CMA	1997-06-10	1998-04-08	Ranging	S-E	1684.5 MHz	1000 kHz	linear	500 kBit/s	D	Backup station
FY-2B	CMA	2000-06-25	2004	CDAS	S-E	1681.6 MHz	20000 kHz	linear	14000 kBit/s	D	Raw data
FY-2B	CMA	2000-06-25	2004	S-VISSR	E-S	2047.5 MHz	2000 kHz	linear	660 kBit/s	D	High-resolution data
FY-2B	CMA	2000-06-25	2004	S-VISSR	S-E	1687.5 MHz	2000 kHz	linear	660 kBit/s	D	High-resolution data
FY-2B	CMA	2000-06-25	2004	WEFAX	E-S	2051 MHz	260 kHz	linear	1.7 kHz	A	Selected data
FY-2B	CMA	2000-06-25	2004	WEFAX	S-E	1691 MHz	260 kHz	linear	1.7 kHz	A	Selected data
FY-2B	CMA	2000-06-25	2004	DCP	E-S	401.1 - 401.4 MHz	3 kHz	RHCP	0.600 kBit/s	D	Regional DCP reports
FY-2B	CMA	2000-06-25	2004	DCP	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports
FY-2B	CMA	2000-06-25	2004	Ranging	E-S	2050.5 MHz	1000 kHz	linear	500 kBit/s	D	Primary station
FY-2B	CMA	2000-06-25	2004	Ranging	S-E	1690.5 MHz	1000 kHz	linear	500 kBit/s	D	Primary station
FY-2B	CMA	2000-06-25	2004	Ranging	E-S	2046.5 MHz	1000 kHz	linear	500 kBit/s	D	Secondary station
FY-2B	CMA	2000-06-25	2004	Ranging	S-E	1686.5 MHz	1000 kHz	linear	500 kBit/s	D	Secondary station
FY-2B	CMA	2000-06-25	2004	Ranging	E-S	2044.5 MHz	1000 kHz	linear	500 kBit/s	D	Backup station
FY-2B	CMA	2000-06-25	2004	Ranging	S-E	1684.5 MHz	1000 kHz	linear	500 kBit/s	D	Backup station
FY-2C	CMA	2004-10-19	2009-11-23	CDAS	S-E	1681.6 MHz	20000 kHz	linear	14000 kBit/s	D	Raw data
FY-2C	CMA	2004-10-19	2009-11-23	S-VISSR	E-S	2047.5 MHz	2000 kHz	linear	660 kBit/s	D	High-resolution data
FY-2C	CMA	2004-10-19	2009-11-23	S-VISSR	S-E	1687.5 MHz	2000 kHz	linear	660 kBit/s	D	High-resolution data
FY-2C	CMA	2004-10-19	2009-11-23	LRIT	E-S	2051 MHz	260 kHz	linear	150 kBit/s	D	Selected data
FY-2C	CMA	2004-10-19	2009-11-23	LRIT	S-E	1690.5 MHz	1000 kHz	linear	150 kBit/s	D	Selected data
FY-2C	CMA	2004-10-19	2009-11-23	DCP	E-S	401.1 - 401.4 MHz	3 kHz	RHCP	0.600 kBit/s	D	Regional DCP reports
FY-2C	CMA	2004-10-19	2009-11-23	DCP	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports
FY-2C	CMA	2004-10-19	2009-11-23	Ranging	E-S	2050.5 MHz	1000 kHz	linear	500 kBit/s	D	Primary station
FY-2C	CMA	2004-10-19	2009-11-23	Ranging	S-E	1690.5 MHz	1000 kHz	linear	500 kBit/s	D	Primary station
FY-2C	CMA	2004-10-19	2009-11-23	Ranging	E-S	2046.5 MHz	1000 kHz	linear	500 kBit/s	D	Secondary station
FY-2C	CMA	2004-10-19	2009-11-23	Ranging	S-E	1686.5 MHz	1000 kHz	linear	500 kBit/s	D	Secondary station
FY-2C	CMA	2004-10-19	2009-11-23	Ranging	E-S	2044.5 MHz	1000 kHz	linear	500 kBit/s	D	Backup station
FY-2C	CMA	2004-10-19	2009-11-23	Ranging	S-E	1684.5 MHz	1000 kHz	linear	500 kBit/s	D	Backup station
FY-2D	CMA	2006-12-08	2015	CDAS	S-E	1681.6 MHz	20000 kHz	linear	14000 kBit/s	D	Raw data
FY-2D	CMA	2006-12-08	2015	S-VISSR	E-S	2047.5 MHz	2000 kHz	linear	660 kBit/s	D	High-resolution data
FY-2D	CMA	2006-12-08	2015	S-VISSR	S-E	1687.5 MHz	2000 kHz	linear	660 kBit/s	D	High-resolution data
FY-2D	CMA	2006-12-08	2015	LRIT	E-S	2051 MHz	260 kHz	linear	150 kBit/s	D	Selected data (not in use)
FY-2D	CMA	2006-12-08	2015	LRIT	S-E	1690.5 MHz	1000 kHz	linear	150 kBit/s	D	Selected data (not in use)
FY-2D	CMA	2006-12-08	2015	DCP	E-S	401.1 - 401.4 MHz	3 kHz	RHCP	0.600 kBit/s	D	Regional DCP reports
FY-2D	CMA	2006-12-08	2015	DCP	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports
FY-2D	CMA	2006-12-08	2015	Ranging	E-S	2050.5 MHz	1000 kHz	linear	500 kBit/s	D	Primary station
FY-2D	CMA	2006-12-08	2015	Ranging	S-E	1690.5 MHz	1000 kHz	linear	500 kBit/s	D	Primary station
FY-2D	CMA	2006-12-08	2015	Ranging	E-S	2046.5 MHz	1000 kHz	linear	500 kBit/s	D	Secondary station
FY-2D	CMA	2006-12-08	2015	Ranging	S-E	1686.5 MHz	1000 kHz	linear	500 kBit/s	D	Secondary station
FY-2D	CMA	2006-12-08	2015	Ranging	E-S	2044.5 MHz	1000 kHz	linear	500 kBit/s	D	Backup station
FY-2D	CMA	2006-12-08	2015	Ranging	S-E	1684.5 MHz	1000 kHz	linear	500 kBit/s	D	Backup station
FY-2E	CMA	2008-12-23	2018-12-31	CDAS	S-E	1681.6 MHz	20000 kHz	linear	14000 kBit/s	D	Raw data
FY-2E	CMA	2008-12-23	2018-12-31	S-VISSR	E-S	2047.5 MHz	2000 kHz	linear	660 kBit/s	D	High-resolution data
FY-2E	CMA	2008-12-23	2018-12-31	S-VISSR	S-E	1687.5 MHz	2000 kHz	linear	660 kBit/s	D	High-resolution data
FY-2E	CMA	2008-12-23	2018-12-31	LRIT	E-S	2051 MHz	260 kHz	linear	150 kBit/s	D	Selected data (not in use)
FY-2E	CMA	2008-12-23	2018-12-31	LRIT	S-E	1690.5 MHz	1000 kHz	linear	150 kBit/s	D	Selected data (not in use)
FY-2E	CMA	2008-12-23	2018-12-31	DCP	E-S	401.1 - 401.4 MHz	3 kHz	RHCP	0.600 kBit/s	D	Regional DCP reports
FY-2E	CMA	2008-12-23	2018-12-31	DCP	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports
FY-2E	CMA	2008-12-23	2018-12-31	Ranging	E-S	2050.5 MHz	1000 kHz	linear	500 kBit/s	D	Primary station
FY-2E	CMA	2008-12-23	2018-12-31	Ranging	S-E	1690.5 MHz	1000 kHz	linear	500 kBit/s	D	Primary station
FY-2E	CMA	2008-12-23	2018-12-31	Ranging	E-S	2046.5 MHz	1000 kHz	linear	500 kBit/s	D	Secondary station
FY-2E	CMA	2008-12-23	2018-12-31	Ranging	S-E	1686.5 MHz	1000 kHz	linear	500 kBit/s	D	Secondary station
FY-2E	CMA	2008-12-23	2018-12-31	Ranging	E-S	2044.5 MHz	1000 kHz	linear	500 kBit/s	D	Backup station
FY-2E	CMA	2008-12-23	2018-12-31	Ranging	S-E	1684.5 MHz	1000 kHz	linear	500 kBit/s	D	Backup station
FY-2F	CMA	2012-01-13	2022-04-01	CDAS	S-E	1681.6 MHz	20000 kHz	linear	14000 kBit/s	D	Raw data
FY-2F	CMA	2012-01-13	2022-04-01	S-VISSR	E-S	2047.5 MHz	2000 kHz	linear	660 kBit/s	D	High-resolution data
FY-2F	CMA	2012-01-13	2022-04-01	S-VISSR	S-E	1687.5 MHz	2000 kHz	linear	660 kBit/s	D	High-resolution data
FY-2F	CMA	2012-01-13	2022-04-01	LRIT	E-S	2051 MHz	260 kHz	linear	150 kBit/s	D	Selected data
FY-2F	CMA	2012-01-13	2022-04-01	LRIT	S-E	1690.5 MHz	1000 kHz	linear	150 kBit/s	D	Selected data
FY-2F	CMA	2012-01-13	2022-04-01	DCP	E-S	401.1 - 401.4 MHz	3 kHz	RHCP	0.600 kBit/s	D	Regional DCP reports
FY-2F	CMA	2012-01-13	2022-04-01	DCP	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports
FY-2F	CMA	2012-01-13	2022-04-01	Ranging	E-S	2050.5 MHz	1000 kHz	linear	500 kBit/s	D	Primary station
FY-2F	CMA	2012-01-13	2022-04-01	Ranging	S-E	1690.5 MHz	1000 kHz	linear	500 kBit/s	D	Primary station
FY-2F	CMA	2012-01-13	2022-04-01	Ranging	E-S	2046.5 MHz	1000 kHz	linear	500 kBit/s	D	Secondary station
FY-2F	CMA	2012-01-13	2022-04-01	Ranging	S-E	1686.5 MHz	1000 kHz	linear	500 kBit/s	D	Secondary station
FY-2F	CMA	2012-01-13	2022-04-01	Ranging	E-S	2044.5 MHz	1000 kHz	linear	500 kBit/s	D	Backup station
FY-2F	CMA	2012-01-13	2022-04-01	Ranging	S-E	1684.5 MHz	1000 kHz	linear	500 kBit/s	D	Backup station
FY-2G	CMA	2014-12-31	≥2022	CDAS	S-E	1681.6 MHz	20000 kHz	linear	14000 kBit/s	D	Raw data
FY-2G	CMA	2014-12-31	≥2022	S-VISSR	E-S	2047.5 MHz	2000 kHz	linear	660 kBit/s	D	High-resolution data
FY-2G	CMA	2014-12-31	≥2022	S-VISSR	S-E	1687.5 MHz	2000 kHz	linear	660 kBit/s	D	High-resolution data
FY-2G	CMA	2014-12-31	≥2022	LRIT	E-S	2051 MHz	260 kHz	linear	150 kBit/s	D	Selected data
FY-2G	CMA	2014-12-31	≥2022	LRIT	S-E	1690.5 MHz	1000 kHz	linear	150 kBit/s	D	Selected data
FY-2G	CMA	2014-12-31	≥2022	DCP	E-S	401.1 - 401.4 MHz	3 kHz	RHCP	0.600 kBit/s	D	Regional DCP reports
FY-2G	CMA	2014-12-31	≥2022	DCP	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports
FY-2G	CMA	2014-12-31	≥2022	Ranging	E-S	2050.5 MHz	1000 kHz	linear	500 kBit/s	D	Primary station
FY-2G	CMA	2014-12-31	≥2022	Ranging	S-E	1690.5 MHz	1000 kHz	linear	500 kBit/s	D	Primary station
FY-2G	CMA	2014-12-31	≥2022	Ranging	E-S	2046.5 MHz	1000 kHz	linear	500 kBit/s	D	Secondary station
FY-2G	CMA	2014-12-31	≥2022	Ranging	S-E	1686.5 MHz	1000 kHz	linear	500 kBit/s	D	Secondary station
FY-2G	CMA	2014-12-31	≥2022	Ranging	E-S	2044.5 MHz	1000 kHz	linear	500 kBit/s	D	Backup station
FY-2G	CMA	2014-12-31	≥2022	Ranging	S-E	1684.5 MHz	1000 kHz	linear	500 kBit/s	D	Backup station
FY-2H	CMA	2018-06-05	≥2022	CDAS	S-E	1681.6 MHz	20000 kHz	linear	14000 kBit/s	D	Raw data
FY-2H	CMA	2018-06-05	≥2022	S-VISSR	E-S	2047.5 MHz	2000 kHz	linear	660 kBit/s	D	High-resolution data
FY-2H	CMA	2018-06-05	≥2022	S-VISSR	S-E	1687.5 MHz	2000 kHz	linear	660 kBit/s	D	High-resolution data
FY-2H	CMA	2018-06-05	≥2022	LRIT	E-S	2051 MHz	260 kHz	linear	150 kBit/s	D	Selected data
FY-2H	CMA	2018-06-05	≥2022	LRIT	S-E	1690.5 MHz	1000 kHz	linear	150 kBit/s	D	Selected data
FY-2H	CMA	2018-06-05	≥2022	DCP	E-S	401.1 - 401.4 MHz	3 kHz	RHCP	0.600 kBit/s	D	Regional DCP reports
FY-2H	CMA	2018-06-05	≥2022	DCP	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports
FY-2H	CMA	2018-06-05	≥2022	Ranging	E-S	2050.5 MHz	1000 kHz	linear	500 kBit/s	D	Primary station
FY-2H	CMA	2018-06-05	≥2022	Ranging	S-E	1690.5 MHz	1000 kHz	linear	500 kBit/s	D	Primary station
FY-2H	CMA	2018-06-05	≥2022	Ranging	E-S	2046.5 MHz	1000 kHz	linear	500 kBit/s	D	Secondary station
FY-2H	CMA	2018-06-05	≥2022	Ranging	S-E	1686.5 MHz	1000 kHz	linear	500 kBit/s	D	Secondary station
FY-2H	CMA	2018-06-05	≥2022	Ranging	E-S	2044.5 MHz	1000 kHz	linear	500 kBit/s	D	Backup station
FY-2H	CMA	2018-06-05	≥2022	Ranging	S-E	1684.5 MHz	1000 kHz	linear	500 kBit/s	D	Backup station
FY-3A	CMA	2008-05-27	2015-01-05	DPT	S-E	8145.95 MHz	149000 kHz	RHCP	93000 kBit/s	D	Stored data
FY-3A	CMA	2008-05-27	2015-01-05	MPT	S-E	7775 MHz	45000 kHz	RHCP	18700 kBit/s	D	Full-resolution MERSI data
FY-3A	CMA	2008-05-27	2015-01-05	AHRPT	S-E	1704.5 MHz	6800 kHz	RHCP	4200 kBit/s	D	Other instrument data
FY-3B	CMA	2010-11-04	2021-12-09	DPT	S-E	8145.95 MHz	149000 kHz	RHCP	93000 kBit/s	D	Stored data
FY-3B	CMA	2010-11-04	2021-12-09	MPT	S-E	7775 MHz	45000 kHz	RHCP	18700 kBit/s	D	Full-resolution MERSI data
FY-3B	CMA	2010-11-04	2021-12-09	AHRPT	S-E	1704.5 MHz	6800 kHz	RHCP	4200 kBit/s	D	Other instrument data
FY-3C	CMA	2013-09-23	≥2022	DPT	S-E	8175 MHz	300000 kHz	LHCP	225000 kBit/s	D	Stored data
FY-3C	CMA	2013-09-23	≥2022	MPT	S-E	7780 MHz	60000 kHz	LHCP	45000 kBit/s	D	Full-resolution MERSI data
FY-3C	CMA	2013-09-23	≥2022	AHRPT	S-E	1701.4 MHz	6800 kHz	RHCP	4200 kBit/s	D	Other instrument data
FY-3D	CMA	2017-11-14	≥2023	AHRPT	S-E	7820 MHz	100000 kHz	RHCP	60000 kBit/s	D	Full-resolution data
FY-4A	CMA	2016-12-10	≥2023	CDAS	S-E	7500 MHz	100000 kHz	RHCP&LHCP		D	Raw data
FY-4A	CMA	2016-12-10	≥2023	HRIT	E-S	8185 MHz	20000 kHz	RHCP		D	High-resolution data
FY-4A	CMA	2016-12-10	≥2023	HRIT	E-S	8205 MHz	20000 kHz	RHCP		D	High-resolution data
FY-4A	CMA	2016-12-10	≥2023	HRIT	S-E	1681 MHz	12000 kHz	linear		D	High-resolution data
FY-4A	CMA	2016-12-10	≥2023	LRIT & WAIB	E-S	2057 MHz	1000 kHz	RHCP		D	Selected data and information
FY-4A	CMA	2016-12-10	≥2023	LRIT & WAIB	S-E	1697 MHz	2000 kHz	linear		D	Selected data and information
FY-4A	CMA	2016-12-10	≥2023	TARS	E-S	2047 MHz	10000 kHz	RHCP		D	Ranging
FY-4A	CMA	2016-12-10	≥2023	TARS	S-E	2227 MHz	10000 kHz	RHCP		D	Ranging
FY-4A	CMA	2016-12-10	≥2023	TARS	S-E	1693 MHz	8000 kHz	linear		D	Ranging
FY-4A	CMA	2016-12-10	≥2023	T&C	E-S	2067.5 MHz	85000 kHz	RHCP		D	Telemetry and commands
FY-4A	CMA	2016-12-10	≥2023	T&C	S-E	2245 MHz	90000 kHz	RHCP		D	Telemetry and commands
GOES-10	NOAA	1997-04-25	2006-12-01	SDL	S-E	1676 MHz	5000 kHz	linear	2620 kBit/s	D	Raw data
GOES-10	NOAA	1997-04-25	2006-12-01	PDR/GVAR	E-S	2027.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-10	NOAA	1997-04-25	2006-12-01	PDR/GVAR	S-E	1685.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-10	NOAA	1997-04-25	2006-12-01	WEFAX	E-S	2033 MHz	50 kHz	RHCP	36 kHz	A	Selected data
GOES-10	NOAA	1997-04-25	2006-12-01	WEFAX	S-E	1691 MHz	50 kHz	linear	35 kHz	A	Selected data
GOES-10	NOAA	1997-04-25	2006-12-01	LRIT	E-S	2033 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data
GOES-10	NOAA	1997-04-25	2006-12-01	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data
GOES-10	NOAA	1997-04-25	2006-12-01	MDL	S-E	1681.478 MHz	200 kHz	RHCP	32 kBit/s	D	Multiuse Data Link
GOES-10	NOAA	1997-04-25	2006-12-01	DCPI	E-S	2034.8875 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-10	NOAA	1997-04-25	2006-12-01	DCPI	E-S	2034.9 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-10	NOAA	1997-04-25	2006-12-01	DCPI	E-S	2034.9125 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-10	NOAA	1997-04-25	2006-12-01	DCPI	S-E	468.8125 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-10	NOAA	1997-04-25	2006-12-01	DCPI	S-E	468.825 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-10	NOAA	1997-04-25	2006-12-01	DCPI	S-E	468.8375 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-10 (S-America)	NOAA	2006-12-01	2009-12-02	SDL	S-E	1676 MHz	5000 kHz	linear	2620 kBit/s	D	Raw data
GOES-10 (S-America)	NOAA	2006-12-01	2009-12-02	PDR/GVAR	E-S	2027.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-10 (S-America)	NOAA	2006-12-01	2009-12-02	PDR/GVAR	S-E	1685.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-10 (S-America)	NOAA	2006-12-01	2009-12-02	WEFAX	E-S	2033 MHz	50 kHz	RHCP	36 kHz	A	Selected data
GOES-10 (S-America)	NOAA	2006-12-01	2009-12-02	WEFAX	S-E	1691 MHz	50 kHz	linear	35 kHz	A	Selected data
GOES-10 (S-America)	NOAA	2006-12-01	2009-12-02	LRIT	E-S	2033 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data
GOES-10 (S-America)	NOAA	2006-12-01	2009-12-02	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data
GOES-10 (S-America)	NOAA	2006-12-01	2009-12-02	MDL	S-E	1681.478 MHz	200 kHz	RHCP	32 kBit/s	D	Multiuse Data Link
GOES-10 (S-America)	NOAA	2006-12-01	2009-12-02	DCPI	E-S	2034.8875 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-10 (S-America)	NOAA	2006-12-01	2009-12-02	DCPI	E-S	2034.9 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-10 (S-America)	NOAA	2006-12-01	2009-12-02	DCPI	E-S	2034.9125 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-10 (S-America)	NOAA	2006-12-01	2009-12-02	DCPI	S-E	468.8125 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-10 (S-America)	NOAA	2006-12-01	2009-12-02	DCPI	S-E	468.825 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-10 (S-America)	NOAA	2006-12-01	2009-12-02	DCPI	S-E	468.8375 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-11	NOAA	2000-05-03	2011-12-05	SDL	S-E	1676 MHz	5000 kHz	linear	2620 kBit/s	D	Raw data
GOES-11	NOAA	2000-05-03	2011-12-05	PDR/GVAR	E-S	2027.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-11	NOAA	2000-05-03	2011-12-05	PDR/GVAR	S-E	1685.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-11	NOAA	2000-05-03	2011-12-05	WEFAX	E-S	2033 MHz	50 kHz	RHCP	36 kHz	A	Ceased October 2005
GOES-11	NOAA	2000-05-03	2011-12-05	WEFAX	S-E	1691 MHz	50 kHz	linear	35 kHz	A	Ceased October 2005
GOES-11	NOAA	2000-05-03	2011-12-05	LRIT	E-S	2033 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data
GOES-11	NOAA	2000-05-03	2011-12-05	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data
GOES-11	NOAA	2000-05-03	2011-12-05	MDL	S-E	1681.478 MHz	200 kHz	RHCP	100 kBit/s	D	Multiuse Data Link
GOES-11	NOAA	2000-05-03	2011-12-05	DCPI	E-S	2034.8875 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-11	NOAA	2000-05-03	2011-12-05	DCPI	E-S	2034.9 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-11	NOAA	2000-05-03	2011-12-05	DCPI	E-S	2034.9125 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-11	NOAA	2000-05-03	2011-12-05	DCPI	S-E	468.8125 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-11	NOAA	2000-05-03	2011-12-05	DCPI	S-E	468.825 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-11	NOAA	2000-05-03	2011-12-05	DCPI	S-E	468.8375 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-12	NOAA	2001-07-23	2010-05-10	SDL	S-E	1676 MHz	5000 kHz	linear	2620 kBit/s	D	Raw data
GOES-12	NOAA	2001-07-23	2010-05-10	PDR/GVAR	E-S	2027.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-12	NOAA	2001-07-23	2010-05-10	PDR/GVAR	S-E	1685.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-12	NOAA	2001-07-23	2010-05-10	WEFAX	E-S	2033 MHz	50 kHz	RHCP	36 kHz	A	Ceased October 2005
GOES-12	NOAA	2001-07-23	2010-05-10	WEFAX	S-E	1691 MHz	50 kHz	linear	35 kHz	A	Ceased October 2005
GOES-12	NOAA	2001-07-23	2010-05-10	LRIT	E-S	2033 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data
GOES-12	NOAA	2001-07-23	2010-05-10	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data
GOES-12	NOAA	2001-07-23	2010-05-10	MDL	S-E	1681.478 MHz	200 kHz	RHCP	100 kBit/s	D	Multiuse Data Link
GOES-12	NOAA	2001-07-23	2010-05-10	DCPI	E-S	2034.8875 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-12	NOAA	2001-07-23	2010-05-10	DCPI	E-S	2034.9 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-12	NOAA	2001-07-23	2010-05-10	DCPI	E-S	2034.9125 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-12	NOAA	2001-07-23	2010-05-10	DCPI	S-E	468.8125 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-12	NOAA	2001-07-23	2010-05-10	DCPI	S-E	468.825 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-12	NOAA	2001-07-23	2010-05-10	DCPI	S-E	468.8375 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-12 (S-America)	NOAA	2010-05-10	2013-08-16	SDL	S-E	1676 MHz	5000 kHz	linear	2620 kBit/s	D	Raw data
GOES-12 (S-America)	NOAA	2010-05-10	2013-08-16	PDR/GVAR	E-S	2027.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-12 (S-America)	NOAA	2010-05-10	2013-08-16	PDR/GVAR	S-E	1685.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-12 (S-America)	NOAA	2010-05-10	2013-08-16	LRIT	E-S	2033 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data
GOES-12 (S-America)	NOAA	2010-05-10	2013-08-16	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data
GOES-12 (S-America)	NOAA	2010-05-10	2013-08-16	MDL	S-E	1681.478 MHz	200 kHz	RHCP	32 kBit/s	D	Multiuse Data Link
GOES-12 (S-America)	NOAA	2010-05-10	2013-08-16	DCPI	E-S	2034.8875 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-12 (S-America)	NOAA	2010-05-10	2013-08-16	DCPI	E-S	2034.9 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-12 (S-America)	NOAA	2010-05-10	2013-08-16	DCPI	E-S	2034.9125 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-12 (S-America)	NOAA	2010-05-10	2013-08-16	DCPI	S-E	468.8125 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-12 (S-America)	NOAA	2010-05-10	2013-08-16	DCPI	S-E	468.825 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-12 (S-America)	NOAA	2010-05-10	2013-08-16	DCPI	S-E	468.8375 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-13	NOAA	2006-05-24	2019	CDA	S-E	1676 MHz	5000 kHz	linear	2620 kBit/s	D	Raw data
GOES-13	NOAA	2006-05-24	2019	CDA	S-E	1676 MHz	5000 kHz	linear	2620 kBit/s	D	Raw data
GOES-13	NOAA	2006-05-24	2019	PDR	E-S	2027.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-13	NOAA	2006-05-24	2019	PDR	E-S	2027.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-13	NOAA	2006-05-24	2019	PDR	S-E	1685.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-13	NOAA	2006-05-24	2019	PDR	S-E	1685.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-13	NOAA	2006-05-24	2019	LRIT	E-S	2033 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data
GOES-13	NOAA	2006-05-24	2019	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data
GOES-13	NOAA	2006-05-24	2019	MDL	S-E	1681.478 MHz	200 kHz	linear	100 kBit/s	D	Multiuse Data Link
GOES-13	NOAA	2006-05-24	2019	MDL	S-E	1681.478 MHz	400 kHz	linear	100 kBit/s	D	Multiuse Data Link
GOES-13	NOAA	2006-05-24	2019	DCPI	E-S	2034.8875 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-13	NOAA	2006-05-24	2019	DCPI	E-S	2034.9 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-13	NOAA	2006-05-24	2019	DCPI	E-S	2034.9125 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-13	NOAA	2006-05-24	2019	DCPI	S-E	468.8125 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-13	NOAA	2006-05-24	2019	DCPI	S-E	468.825 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-13	NOAA	2006-05-24	2019	DCPI	S-E	468.8375 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-14	NOAA	2009-06-27	≥2022	CDA	S-E	1676 MHz	5000 kHz	linear	2620 kBit/s	D	Raw data
GOES-14	NOAA	2009-06-27	≥2022	CDA	S-E	1676 MHz	5000 kHz	linear	2620 kBit/s	D	Raw data
GOES-14	NOAA	2009-06-27	≥2022	PDR	E-S	2027.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-14	NOAA	2009-06-27	≥2022	PDR	E-S	2027.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-14	NOAA	2009-06-27	≥2022	PDR	S-E	1685.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-14	NOAA	2009-06-27	≥2022	PDR	S-E	1685.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-14	NOAA	2009-06-27	≥2022	LRIT	E-S	2033 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data
GOES-14	NOAA	2009-06-27	≥2022	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data
GOES-14	NOAA	2009-06-27	≥2022	MDL	S-E	1681.478 MHz	200 kHz	linear	100 kBit/s	D	Multiuse Data Link
GOES-14	NOAA	2009-06-27	≥2022	MDL	S-E	1681.478 MHz	400 kHz	linear	100 kBit/s	D	Multiuse Data Link
GOES-14	NOAA	2009-06-27	≥2022	DCPI	E-S	2034.8875 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-14	NOAA	2009-06-27	≥2022	DCPI	E-S	2034.9 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-14	NOAA	2009-06-27	≥2022	DCPI	E-S	2034.9125 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-14	NOAA	2009-06-27	≥2022	DCPI	S-E	468.8125 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-14	NOAA	2009-06-27	≥2022	DCPI	S-E	468.825 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-14	NOAA	2009-06-27	≥2022	DCPI	S-E	468.8375 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-15	NOAA	2010-03-04	≥2022	CDA	S-E	1676 MHz	5000 kHz	linear	2620 kBit/s	D	Raw data
GOES-15	NOAA	2010-03-04	≥2022	CDA	S-E	1676 MHz	5000 kHz	linear	2620 kBit/s	D	Raw data
GOES-15	NOAA	2010-03-04	≥2022	PDR	E-S	2027.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-15	NOAA	2010-03-04	≥2022	PDR	E-S	2027.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-15	NOAA	2010-03-04	≥2022	PDR	S-E	1685.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-15	NOAA	2010-03-04	≥2022	PDR	S-E	1685.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-15	NOAA	2010-03-04	≥2022	LRIT	E-S	2033 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data
GOES-15	NOAA	2010-03-04	≥2022	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data
GOES-15	NOAA	2010-03-04	≥2022	MDL	S-E	1681.478 MHz	200 kHz	linear	100 kBit/s	D	Multiuse Data Link
GOES-15	NOAA	2010-03-04	≥2022	MDL	S-E	1681.478 MHz	400 kHz	linear	100 kBit/s	D	Multiuse Data Link
GOES-15	NOAA	2010-03-04	≥2022	DCPI	E-S	2034.8875 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-15	NOAA	2010-03-04	≥2022	DCPI	E-S	2034.9 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-15	NOAA	2010-03-04	≥2022	DCPI	E-S	2034.9125 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-15	NOAA	2010-03-04	≥2022	DCPI	S-E	468.8125 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-15	NOAA	2010-03-04	≥2022	DCPI	S-E	468.825 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-15	NOAA	2010-03-04	≥2022	DCPI	S-E	468.8375 MHz	10 kHz	RHCP	2.4 kBit/s	D	DCP interrogation
GOES-16	NOAA	2016-11-19	≥2027	Raw Data Link	S-E	8220 MHz	120000 kHz	linear	120000 kBit/s	D	Raw data
GOES-16	NOAA	2016-11-19	≥2027	GRB	E-S	7216.6 MHz	10900 kHz	RHCP&LHCP	17332 kBit/s	D	Processed images/soundings
GOES-16	NOAA	2016-11-19	≥2027	GRB	E-S	7216.6 MHz	9790 kHz	RHCP&LHCP	23480 kBit/s	D	Processed images/soundings
GOES-16	NOAA	2016-11-19	≥2027	GRB	S-E	1686.6 MHz	10900 kHz	RHCP&LHCP	17332 kBit/s	D	Processed images/soundings
GOES-16	NOAA	2016-11-19	≥2027	GRB	S-E	1686.6 MHz	9790 kHz	RHCP&LHCP	23480 kBit/s	D	Processed images/soundings
GOES-16	NOAA	2016-11-19	≥2027	HRIT/EMWIN	E-S	2027.1 MHz	1206 kHz	linear	927 kBit/s	D	Selected data and information
GOES-16	NOAA	2016-11-19	≥2027	HRIT/EMWIN	S-E	1694.1 MHz	1210 kHz	linear	927 kBit/s	D	Selected data and information
GOES-17	NOAA	2018-03-01	≥2029	Raw Data Link	S-E	8220 MHz	120000 kHz	linear	120000 kBit/s	D	Raw data
GOES-17	NOAA	2018-03-01	≥2029	GRB	E-S	7216.6 MHz	10900 kHz	RHCP&LHCP	17332 kBit/s	D	Processed images/soundings
GOES-17	NOAA	2018-03-01	≥2029	GRB	E-S	7216.6 MHz	9790 kHz	RHCP&LHCP	23480 kBit/s	D	Processed images/soundings
GOES-17	NOAA	2018-03-01	≥2029	GRB	S-E	1686.6 MHz	10900 kHz	RHCP&LHCP	17332 kBit/s	D	Processed images/soundings
GOES-17	NOAA	2018-03-01	≥2029	GRB	S-E	1686.6 MHz	9790 kHz	RHCP&LHCP	23480 kBit/s	D	Processed images/soundings
GOES-17	NOAA	2018-03-01	≥2029	HRIT/EMWIN	S-E	1694.1 MHz	1210 kHz	linear	927 kBit/s	D	Selected data and information
GOES-18	NOAA	2022-03-01	≥2033	Raw Data Link	S-E	8220 MHz	120000 kHz	linear	120000 kBit/s	D	Raw data
GOES-18	NOAA	2022-03-01	≥2033	GRB	E-S	7216.6 MHz	10900 kHz	RHCP&LHCP	17332 kBit/s	D	Processed images/soundings
GOES-18	NOAA	2022-03-01	≥2033	GRB	E-S	7216.6 MHz	9790 kHz	RHCP&LHCP	23480 kBit/s	D	Processed images/soundings
GOES-18	NOAA	2022-03-01	≥2033	GRB	S-E	1686.6 MHz	10900 kHz	RHCP&LHCP	17332 kBit/s	D	Processed images/soundings
GOES-18	NOAA	2022-03-01	≥2033	GRB	S-E	1686.6 MHz	9790 kHz	RHCP&LHCP	23480 kBit/s	D	Processed images/soundings
GOES-18	NOAA	2022-03-01	≥2033	HRIT/EMWIN	S-E	1694.1 MHz	1210 kHz	linear	927 kBit/s	D	Selected data and information
GOES-8	NOAA	1994-04-13	2004-05-05	SDL	S-E	1676 MHz	5000 kHz	linear	2620 kBit/s	D	Raw data
GOES-8	NOAA	1994-04-13	2004-05-05	PDR/GVAR	E-S	2027.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-8	NOAA	1994-04-13	2004-05-05	PDR/GVAR	S-E	1685.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-8	NOAA	1994-04-13	2004-05-05	WEFAX	E-S	2033 MHz	50 kHz	RHCP	36 kHz	A	Selected data
GOES-8	NOAA	1994-04-13	2004-05-05	WEFAX	S-E	1691 MHz	50 kHz	linear	35 kHz	A	Selected data
GOES-8	NOAA	1994-04-13	2004-05-05	LRIT	E-S	2033 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data
GOES-8	NOAA	1994-04-13	2004-05-05	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data
GOES-8	NOAA	1994-04-13	2004-05-05	MDL	S-E	1681.478 MHz	200 kHz	RHCP	32 kBit/s	D	Multiuse Data Link
GOES-8	NOAA	1994-04-13	2004-05-05	DCPI	E-S	2034.8875 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-8	NOAA	1994-04-13	2004-05-05	DCPI	E-S	2034.9 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-8	NOAA	1994-04-13	2004-05-05	DCPI	E-S	2034.9125 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-8	NOAA	1994-04-13	2004-05-05	DCPI	S-E	468.8125 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-8	NOAA	1994-04-13	2004-05-05	DCPI	S-E	468.825 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-8	NOAA	1994-04-13	2004-05-05	DCPI	S-E	468.8375 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-9	NOAA	1995-05-23	2003-05-22	SDL	S-E	1676 MHz	5000 kHz	linear	2620 kBit/s	D	Raw data
GOES-9	NOAA	1995-05-23	2003-05-22	PDR/GVAR	E-S	2027.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-9	NOAA	1995-05-23	2003-05-22	PDR/GVAR	S-E	1685.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-9	NOAA	1995-05-23	2003-05-22	WEFAX	E-S	2033 MHz	50 kHz	RHCP	36 kHz	A	Selected data
GOES-9	NOAA	1995-05-23	2003-05-22	WEFAX	S-E	1691 MHz	50 kHz	linear	35 kHz	A	Selected data
GOES-9	NOAA	1995-05-23	2003-05-22	LRIT	E-S	2033 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data
GOES-9	NOAA	1995-05-23	2003-05-22	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data
GOES-9	NOAA	1995-05-23	2003-05-22	MDL	S-E	1681.478 MHz	200 kHz	RHCP	32 kBit/s	D	Multiuse Data Link
GOES-9	NOAA	1995-05-23	2003-05-22	DCPI	E-S	2034.8875 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-9	NOAA	1995-05-23	2003-05-22	DCPI	E-S	2034.9 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-9	NOAA	1995-05-23	2003-05-22	DCPI	E-S	2034.9125 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-9	NOAA	1995-05-23	2003-05-22	DCPI	S-E	468.8125 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-9	NOAA	1995-05-23	2003-05-22	DCPI	S-E	468.825 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-9	NOAA	1995-05-23	2003-05-22	DCPI	S-E	468.8375 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-9 (GMS backup)	NOAA	2003-05-22	2006-07-24	SDL	S-E	1676 MHz	5000 kHz	linear	2620 kBit/s	D	Raw data
GOES-9 (GMS backup)	NOAA	2003-05-22	2006-07-24	PDR/GVAR	E-S	2027.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-9 (GMS backup)	NOAA	2003-05-22	2006-07-24	PDR/GVAR	S-E	1685.7 MHz	4000 kHz	linear	2110 kBit/s	D	Processed images/soundings
GOES-9 (GMS backup)	NOAA	2003-05-22	2006-07-24	WEFAX	E-S	2033 MHz	50 kHz	RHCP	36 kHz	A	Selected data
GOES-9 (GMS backup)	NOAA	2003-05-22	2006-07-24	WEFAX	S-E	1691 MHz	50 kHz	linear	35 kHz	A	Selected data
GOES-9 (GMS backup)	NOAA	2003-05-22	2006-07-24	LRIT	E-S	2033 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data
GOES-9 (GMS backup)	NOAA	2003-05-22	2006-07-24	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data
GOES-9 (GMS backup)	NOAA	2003-05-22	2006-07-24	MDL	S-E	1681.478 MHz	200 kHz	RHCP	32 kBit/s	D	Multiuse Data Link
GOES-9 (GMS backup)	NOAA	2003-05-22	2006-07-24	DCPI	E-S	2034.8875 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-9 (GMS backup)	NOAA	2003-05-22	2006-07-24	DCPI	E-S	2034.9 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-9 (GMS backup)	NOAA	2003-05-22	2006-07-24	DCPI	E-S	2034.9125 MHz	125 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-9 (GMS backup)	NOAA	2003-05-22	2006-07-24	DCPI	S-E	468.8125 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-9 (GMS backup)	NOAA	2003-05-22	2006-07-24	DCPI	S-E	468.825 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-9 (GMS backup)	NOAA	2003-05-22	2006-07-24	DCPI	S-E	468.8375 MHz	200 kHz	RHCP	0.100 kBit/s	D	DCP interrogation
GOES-U	NOAA	≥2024	≥2035	Raw Data Link	S-E	8220 MHz	120000 kHz	linear	120000 kBit/s	D	Raw data
GOES-U	NOAA	≥2024	≥2035	GRB	E-S	7216.6 MHz	10900 kHz	RHCP&LHCP	17332 kBit/s	D	Processed images/soundings
GOES-U	NOAA	≥2024	≥2035	GRB	E-S	7216.6 MHz	9790 kHz	RHCP&LHCP	23480 kBit/s	D	Processed images/soundings
GOES-U	NOAA	≥2024	≥2035	GRB	S-E	1686.6 MHz	10900 kHz	RHCP&LHCP	17332 kBit/s	D	Processed images/soundings
GOES-U	NOAA	≥2024	≥2035	GRB	S-E	1686.6 MHz	9790 kHz	RHCP&LHCP	23480 kBit/s	D	Processed images/soundings
GOES-U	NOAA	≥2024	≥2035	HRIT/EMWIN	E-S	2027.1 MHz	1206 kHz	linear	927 kBit/s	D	Selected data and information
GOES-U	NOAA	≥2024	≥2035	HRIT/EMWIN	S-E	1694.1 MHz	1210 kHz	linear	927 kBit/s	D	Selected data and information
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	CDAS	S-E	1677 MHz	10000 kHz	linear	2700 kBit/s	D	Raw data
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	HRIT	E-S	2029.1 MHz	6000 kHz	linear	3500 kBit/s	D	High resolution data. Service terminated in Dec 2015
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	HRIT	S-E	1687.1 MHz	6000 kHz	linear	3500 kBit/s	D	High resolution data. Service terminated in Dec 2015.
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	HiRID	E-S	2029.1 MHz	2000 kHz	linear	660 kBit/s	D	High resolution data - This service was terminated in March 2008
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	HiRID	S-E	1687.1 MHz	2000 kHz	linear	660 kBit/s	D	High resolution data - This service was terminated in March 2008
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	LRIT	E-S	2033 MHz	250 kHz	linear	150 kBit/s	D	Selected data. Service terminated in Dec 2015.
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	LRIT	S-E	1691 MHz	250 kHz	linear	150 kBit/s	D	Selected data. Service terminated in Dec 2015.
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	WEFAX	E-S	2033 MHz	260 kHz	linear	1.68 kHz	A	Weather facsimile - This service was terminated in March 2008
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	WEFAX	S-E	1691 MHz	260 kHz	linear	1.68 kHz	A	Weather facsimile - This service was terminated in March 2008
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	DCS	E-S	2034.933 MHz	6 kHz	linear	0.1 kBit/s	D	DCP interrogation
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	DCS	E-S	2034.925 MHz	6 kHz	linear	0.1 kBit/s	D	DCP interrogation
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	DCS	E-S	2034.974 MHz	6 kHz	linear	0.1 kBit/s	D	DCP interrogation
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	DCS	E-S	402 - 402.4 MHz	2 kHz	RHCP	0.1 kBit/s	D	DCP reports
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	DCS	E-S	402 - 402.4 MHz	4 kHz	RHCP	0.3 kBit/s	D	DCP reports
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	DCS	E-S	402 - 402.4 MHz	6 kHz	RHCP	0.6 kBit/s	D	DCP reports
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	DCS	S-E	1694.3 - 1694.7 MHz	2 kHz	linear	0.1 kBit/s	D	DCP report relay
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	DCS	S-E	1694.3 - 1694.7 MHz	4 kHz	linear	0.3 kBit/s	D	DCP report relay
Himawari-6 (MTSAT-1R)	JMA	2005-02-26	2015-12-04	DCS	S-E	1694.3 - 1694.7 MHz	6 kHz	linear	0.6 kBit/s	D	DCP report relay
Himawari-7 (MTSAT-2)	JMA	2006-02-18	2016-05-10	CDAS	S-E	1677 MHz	10000 kHz	linear	2700 kBit/s	D	Raw data
Himawari-7 (MTSAT-2)	JMA	2006-02-18	2016-05-10	HRIT	E-S	2029.1 MHz	6000 kHz	linear	3500 kBit/s	D	High resolution data
Himawari-7 (MTSAT-2)	JMA	2006-02-18	2016-05-10	HRIT	S-E	1687.1 MHz	6000 kHz	linear	3500 kBit/s	D	High resolution data
Himawari-7 (MTSAT-2)	JMA	2006-02-18	2016-05-10	LRIT	E-S	2033 MHz	250 kHz	linear	150 kBit/s	D	Selected data
Himawari-7 (MTSAT-2)	JMA	2006-02-18	2016-05-10	LRIT	S-E	1691 MHz	250 kHz	linear	150 kBit/s	D	Selected data
Himawari-7 (MTSAT-2)	JMA	2006-02-18	2016-05-10	DCS	E-S	2034.933 MHz	6 kHz	linear	0.1 kBit/s	D	DCP interrogation
Himawari-7 (MTSAT-2)	JMA	2006-02-18	2016-05-10	DCS	E-S	2034.925 MHz	6 kHz	linear	0.1 kBit/s	D	DCP interrogation
Himawari-7 (MTSAT-2)	JMA	2006-02-18	2016-05-10	DCS	E-S	2034.974 MHz	6 kHz	linear	0.1 kBit/s	D	DCP interrogation
Himawari-7 (MTSAT-2)	JMA	2006-02-18	2016-05-10	DCS	E-S	402 - 402.4 MHz	2 kHz	RHCP	0.1 kBit/s	D	DCP reports
Himawari-7 (MTSAT-2)	JMA	2006-02-18	2016-05-10	DCS	E-S	402 - 402.4 MHz	4 kHz	RHCP	0.3 kBit/s	D	DCP reports
Himawari-7 (MTSAT-2)	JMA	2006-02-18	2016-05-10	DCS	E-S	402 - 402.4 MHz	6 kHz	RHCP	0.6 kBit/s	D	DCP reports
Himawari-7 (MTSAT-2)	JMA	2006-02-18	2016-05-10	DCS	S-E	1694.3 - 1694.7 MHz	2 kHz	linear	0.1 kBit/s	D	DCP report relay
Himawari-7 (MTSAT-2)	JMA	2006-02-18	2016-05-10	DCS	S-E	1694.3 - 1694.7 MHz	4 kHz	linear	0.3 kBit/s	D	DCP report relay
Himawari-7 (MTSAT-2)	JMA	2006-02-18	2016-05-10	DCS	S-E	1694.3 - 1694.7 MHz	6 kHz	linear	0.6 kBit/s	D	DCP report relay
Himawari-8	JMA	2014-10-07	≥2030	CDAS	S-E	18284.6 MHz	110000 kHz	linear	66000 kBit/s	D	Raw data
Himawari-8	JMA	2014-10-07	≥2030	CDAS	S-E	18284.6 MHz	110000 kHz	linear	66000 kBit/s	D	Raw data
Himawari-8	JMA	2014-10-07	≥2030	DCS	E-S	402 - 402.4 MHz	2 kHz	RHCP	0.1 kBit/s	D	DCP reports
Himawari-8	JMA	2014-10-07	≥2030	DCS	E-S	402 - 402.4 MHz	4 kHz	RHCP	0.3 kBit/s	D	DCP reports
Himawari-8	JMA	2014-10-07	≥2030	DCS	E-S	402 - 402.4 MHz	6 kHz	RHCP	0.6 kBit/s	D	DCP reports
Himawari-8	JMA	2014-10-07	≥2030	DCS	S-E	18399 - 18400 MHz	2 kHz	linear	0.1 kBit/s	D	DCP report relay
Himawari-8	JMA	2014-10-07	≥2030	DCS	S-E	18399 - 18400 MHz	4 kHz	linear	0.3 kBit/s	D	DCP report relay
Himawari-8	JMA	2014-10-07	≥2030	DCS	S-E	18399 - 18400 MHz	6 kHz	linear	0.6 kBit/s	D	DCP report relay
Himawari-9	JMA	2016-11-02	≥2030	CDAS	S-E	18284.6 MHz	110000 kHz	linear	66000 kBit/s	D	Raw data
Himawari-9	JMA	2016-11-02	≥2030	CDAS	S-E	18284.6 MHz	110000 kHz	linear	66000 kBit/s	D	Raw data
Himawari-9	JMA	2016-11-02	≥2030	DCS	E-S	402 - 402.4 MHz	2 kHz	RHCP	0.1 kBit/s	D	DCP reports
Himawari-9	JMA	2016-11-02	≥2030	DCS	E-S	402 - 402.4 MHz	4 kHz	RHCP	0.3 kBit/s	D	DCP reports
Himawari-9	JMA	2016-11-02	≥2030	DCS	E-S	402 - 402.4 MHz	6 kHz	RHCP	0.6 kBit/s	D	DCP reports
Himawari-9	JMA	2016-11-02	≥2030	DCS	S-E	18399 - 18400 MHz	2 kHz	linear	0.1 kBit/s	D	DCP report relay
Himawari-9	JMA	2016-11-02	≥2030	DCS	S-E	18399 - 18400 MHz	4 kHz	linear	0.3 kBit/s	D	DCP report relay
Himawari-9	JMA	2016-11-02	≥2030	DCS	S-E	18399 - 18400 MHz	6 kHz	linear	0.6 kBit/s	D	DCP report relay
INSAT-3A	ISRO	2003-04-10	2016	CDAS	S-E	4501.5 MHz	500 kHz	linear	526.5 kBit/s	D	VHRR raw data
INSAT-3A	ISRO	2003-04-10	2016	CDAS	S-E	4508.93 MHz	500 kHz	linear	1288.5 kBit/s	D	CCD raw data
INSAT-3A	ISRO	2003-04-10	2016	DRT	E-S	402.75 MHz	180 kHz	LHCP	4.8 kBit/s	D	DCP reports
INSAT-3A	ISRO	2003-04-10	2016	DRT	S-E	4504.2 MHz	180 kHz	linear	4.8 kBit/s	D	DCP relay
INSAT-3C	ISRO	2002-01-24	2014	MDD	S-E	2599.23 MHz	200 kHz	linear	10 kHz	A	Meteorological Data Distribution including data originated from INSAT-3A
INSAT-3C	ISRO	2002-01-24	2014	CWDS	S-E	2559.23 MHz	200 kHz	linear	10 kHz	A	Cyclone Warning Dissemination System for selected INSAT-3A data activated in the cyclone season
INSAT-3D	ISRO	2013-07-25	≥2022	CDAS	S-E	4781 MHz	9600 kHz	linear	3927.25 kBit/s	D	IMAGER raw data
INSAT-3D	ISRO	2013-07-25	≥2022	CDAS	S-E	4798 MHz	96 kHz	linear	40.0 kBit/s	D	SOUNDER raw data
INSAT-3D	ISRO	2013-07-25	≥2022	DRT	E-S	402.75 MHz	180 kHz	LHCP	4.8 kBit/s	D	DCP reports
INSAT-3D	ISRO	2013-07-25	≥2022	DRT	S-E	4506.05 MHz	180 kHz	linear	4.8 kBit/s	D	DCP relay
INSAT-3DR	ISRO	2016-09-08	≥2026	CDAS	S-E	4781 MHz	9600 kHz	linear	3927.25 kBit/s	D	IMAGER raw data
INSAT-3DR	ISRO	2016-09-08	≥2026	CDAS	S-E	4798 MHz	96 kHz	linear	40.0 kBit/s	D	SOUNDER raw data
INSAT-3DR	ISRO	2016-09-08	≥2026	DRT	E-S	402.75 MHz	180 kHz	LHCP	4.8 kBit/s	D	DCP reports
INSAT-3DR	ISRO	2016-09-08	≥2026	DRT	S-E	4506.05 MHz	180 kHz	linear	4.8 kBit/s	D	DCP relay
INSAT-3DS	ISRO	≥2023	≥2030	CDAS	S-E	4781 MHz	9600 kHz	linear	3927.25 kBit/s	D	IMAGER raw data
INSAT-3DS	ISRO	≥2023	≥2030	CDAS	S-E	4798 MHz	96 kHz	linear	40.0 kBit/s	D	SOUNDER raw data
INSAT-3DS	ISRO	≥2023	≥2030	DRT	E-S	402.75 MHz	180 kHz	LHCP	4.8 kBit/s	D	DCP reports
INSAT-3DS	ISRO	≥2023	≥2030	DRT	S-E	4506.05 MHz	180 kHz	linear	4.8 kBit/s	D	DCP relay
JASON-2	NASA	2008-06-20	2019-10-01	TM & Raw Data	S-E	5300 MHz	320000 kHz	RHCP&LHCP	320000 kBit/s	D	FM Pulse Radar. Telemetry and Altimeter real-time data
JASON-2	NASA	2008-06-20	2019-10-01	TM & Raw Data	S-E	5300 MHz	100000 kHz	RHCP&LHCP	100000 kBit/s	D	FM Pulse Radar. Telemetry and Altimeter real-time data
JASON-2	NASA	2008-06-20	2019-10-01	TM & Raw Data	S-E	13575 MHz	320000 kHz	RHCP&LHCP	320000 kBit/s	D	FM Pulse Radar. Telemetry and Altimeter real-time data
JASON-2	NASA	2008-06-20	2019-10-01	TM/SMD	S-E	2268.465 MHz	839 kHz	RHCP&LHCP	834 kBit/s	D	Telemetry and Altimeter stored data
JASON-3	NASA	2016-01-17	≥2023	TM & Raw Data	S-E	5300 MHz	320000 kHz	RHCP&LHCP	320000 kBit/s	D	FM Pulse Radar. Telemetry and Altimeter real-time data
JASON-3	NASA	2016-01-17	≥2023	TM & Raw Data	S-E	5300 MHz	100000 kHz	RHCP&LHCP	100000 kBit/s	D	FM Pulse Radar. Telemetry and Altimeter real-time data
JASON-3	NASA	2016-01-17	≥2023	TM & Raw Data	S-E	13575 MHz	320000 kHz	RHCP&LHCP	320000 kBit/s	D	FM Pulse Radar. Telemetry and Altimeter real-time data
JASON-3	NASA	2016-01-17	≥2023	TM/SMD	S-E	2215.92 MHz	2000 kHz	RHCP&LHCP	838.861 kBit/s	D	Telemetry and Altimeter stored data
JPSS-2	NOAA	≥2022-11	≥2029	SMD	S-E	26703.4 MHz	300000 kHz	RHCP	261000 kBit/s	D	Stored Mission Data (info data rate)
JPSS-2	NOAA	≥2022-11	≥2029	SMD	S-E	26703.4 MHz	150000 kHz	RHCP	131000 kBit/s	D	Stored Mission Data (info data rate)
JPSS-2	NOAA	≥2022-11	≥2029	HRD	S-E	7812 MHz	50000 kHz	RHCP	21800 kBit/s	D	Real-time High Rate Data
JPSS-3	NOAA	≥2027	≥2034	SMD	S-E	26703.4 MHz	300000 kHz	RHCP	261000 kBit/s	D	Stored Mission Data (info data rate)
JPSS-3	NOAA	≥2027	≥2034	SMD	S-E	26703.4 MHz	150000 kHz	RHCP	131000 kBit/s	D	Stored Mission Data (info data rate)
JPSS-3	NOAA	≥2027	≥2034	HRD	S-E	7812 MHz	50000 kHz	RHCP	21800 kBit/s	D	Real-time High Rate Data
JPSS-4	NOAA	≥2032	≥2039	SMD	S-E	26703.4 MHz	300000 kHz	RHCP	261000 kBit/s	D	Stored Mission Data (info data rate)
JPSS-4	NOAA	≥2032	≥2039	SMD	S-E	26703.4 MHz	150000 kHz	RHCP	131000 kBit/s	D	Stored Mission Data (info data rate)
JPSS-4	NOAA	≥2032	≥2039	HRD	S-E	7812 MHz	50000 kHz	RHCP	21800 kBit/s	D	Real-time High Rate Data
Kalpana-1	ISRO	2002-09-12	2017	CDAS	S-E	4503.5 MHz	500 kHz	linear	526.5 kBit/s	D	VHRR raw data
Kalpana-1	ISRO	2002-09-12	2017	DRT	E-S	402.75 MHz	180 kHz	LHCP	4.8 kBit/s	D	DCP reports
Kalpana-1	ISRO	2002-09-12	2017	DRT	S-E	4506.05 MHz	180 kHz	linear	4.8 kBit/s	D	DCP relay
Meteor-M N1	RosHydroMet	2009-09-17	2014-09-23	DA	S-E	8128 MHz	30700 kHz	LHCP	15360 kBit/s	D	Stored data
Meteor-M N1	RosHydroMet	2009-09-17	2014-09-23	DA	S-E	8320 MHz	30700 kHz	LHCP	15360 kBit/s	D	Stored data
Meteor-M N1	RosHydroMet	2009-09-17	2014-09-23	DA	S-E	8128 MHz	123000 kHz	LHCP	61440 kBit/s	D	Stored data
Meteor-M N1	RosHydroMet	2009-09-17	2014-09-23	DA	S-E	8320 MHz	123000 kHz	LHCP	61440 kBit/s	D	Stored data
Meteor-M N1	RosHydroMet	2009-09-17	2014-09-23	AHRPT	S-E	1700 MHz	3000 kHz	RHCP	3000 kBit/s	D	High resolution data + DCP reports
Meteor-M N1	RosHydroMet	2009-09-17	2014-09-23	AHRPT	S-E	1705 MHz	3000 kHz	RHCP	3000 kBit/s	D	High resolution data + DCP reports
Meteor-M N1	RosHydroMet	2009-09-17	2014-09-23	LRPT	S-E	137.1 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N1	RosHydroMet	2009-09-17	2014-09-23	LRPT	S-E	137.9 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N1	RosHydroMet	2009-09-17	2014-09-23	LRPT	S-E	137.9125 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N1	RosHydroMet	2009-09-17	2014-09-23	DCS	E-S	401.9 - 402.5 MHz	5 kHz	RHCP	1.2 kBit/s	D	Regional and International DCP reports
Meteor-M N1	RosHydroMet	2009-09-17	2014-09-23	DCS	E-S	401.9 - 402 MHz	5 kHz	RHCP	0.4 kBit/s	D	Regional DCP reports
Meteor-M N2	RosHydroMet	2014-07-08	≥2022	DA	S-E	8128 MHz	30700 kHz	LHCP	15360 kBit/s	D	Stored data
Meteor-M N2	RosHydroMet	2014-07-08	≥2022	DA	S-E	8320 MHz	30700 kHz	LHCP	15360 kBit/s	D	Stored data
Meteor-M N2	RosHydroMet	2014-07-08	≥2022	DA	S-E	8128 MHz	123000 kHz	LHCP	61440 kBit/s	D	Stored data
Meteor-M N2	RosHydroMet	2014-07-08	≥2022	DA	S-E	8320 MHz	123000 kHz	LHCP	61440 kBit/s	D	Stored data
Meteor-M N2	RosHydroMet	2014-07-08	≥2022	AHRPT	S-E	1700 MHz	3000 kHz	RHCP	3000 kBit/s	D	High resolution data + DCP reports
Meteor-M N2	RosHydroMet	2014-07-08	≥2022	AHRPT	S-E	1705 MHz	3000 kHz	RHCP	3000 kBit/s	D	High resolution data + DCP reports
Meteor-M N2	RosHydroMet	2014-07-08	≥2022	LRPT	S-E	137.1 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2	RosHydroMet	2014-07-08	≥2022	LRPT	S-E	137.9 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2	RosHydroMet	2014-07-08	≥2022	LRPT	S-E	137.9125 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2	RosHydroMet	2014-07-08	≥2022	DCS	E-S	401.9 - 402.5 MHz	5 kHz	RHCP	1.2 kBit/s	D	Regional and International DCP reports
Meteor-M N2	RosHydroMet	2014-07-08	≥2022	DCS	E-S	401.9 - 402 MHz	5 kHz	RHCP	0.4 kBit/s	D	Regional DCP reports
Meteor-M N2-1	RosHydroMet	2017-11-28	2017-11-28	DA	S-E	8128 MHz	30700 kHz	LHCP	15360 kBit/s	D	Stored data
Meteor-M N2-1	RosHydroMet	2017-11-28	2017-11-28	DA	S-E	8320 MHz	30700 kHz	LHCP	15360 kBit/s	D	Stored data
Meteor-M N2-1	RosHydroMet	2017-11-28	2017-11-28	DA	S-E	8128 MHz	123000 kHz	LHCP	61440 kBit/s	D	Stored data
Meteor-M N2-1	RosHydroMet	2017-11-28	2017-11-28	DA	S-E	8320 MHz	123000 kHz	LHCP	61440 kBit/s	D	Stored data
Meteor-M N2-1	RosHydroMet	2017-11-28	2017-11-28	AHRPT	S-E	1700 MHz	3000 kHz	RHCP	3000 kBit/s	D	High resolution data + DCP reports
Meteor-M N2-1	RosHydroMet	2017-11-28	2017-11-28	AHRPT	S-E	1705 MHz	3000 kHz	RHCP	3000 kBit/s	D	High resolution data + DCP reports
Meteor-M N2-1	RosHydroMet	2017-11-28	2017-11-28	LRPT	S-E	137.1 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-1	RosHydroMet	2017-11-28	2017-11-28	LRPT	S-E	137.9 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-1	RosHydroMet	2017-11-28	2017-11-28	LRPT	S-E	137.9125 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-1	RosHydroMet	2017-11-28	2017-11-28	DCS	E-S	401.9 - 402.5 MHz	5 kHz	RHCP	1.2 kBit/s	D	Regional and International DCP reports
Meteor-M N2-1	RosHydroMet	2017-11-28	2017-11-28	DCS	E-S	401.9 - 402 MHz	5 kHz	RHCP	0.4 kBit/s	D	Regional DCP reports
Meteor-M N2-2	RosHydroMet	2019-07-05	≥2024	DA	S-E	8128 MHz	30700 kHz	LHCP	15360 kBit/s	D	Stored data
Meteor-M N2-2	RosHydroMet	2019-07-05	≥2024	DA	S-E	8320 MHz	30700 kHz	LHCP	15360 kBit/s	D	Stored data
Meteor-M N2-2	RosHydroMet	2019-07-05	≥2024	DA	S-E	8128 MHz	123000 kHz	LHCP	61440 kBit/s	D	Stored data
Meteor-M N2-2	RosHydroMet	2019-07-05	≥2024	DA	S-E	8320 MHz	123000 kHz	LHCP	61440 kBit/s	D	Stored data
Meteor-M N2-2	RosHydroMet	2019-07-05	≥2024	AHRPT	S-E	1700 MHz	3000 kHz	RHCP	3000 kBit/s	D	High resolution data + DCP reports
Meteor-M N2-2	RosHydroMet	2019-07-05	≥2024	AHRPT	S-E	1705 MHz	3000 kHz	RHCP	3000 kBit/s	D	High resolution data + DCP reports
Meteor-M N2-2	RosHydroMet	2019-07-05	≥2024	LRPT	S-E	137.1 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-2	RosHydroMet	2019-07-05	≥2024	LRPT	S-E	137.9 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-2	RosHydroMet	2019-07-05	≥2024	LRPT	S-E	137.9125 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-2	RosHydroMet	2019-07-05	≥2024	DCS	E-S	401.9 - 402.5 MHz	5 kHz	RHCP	1.2 kBit/s	D	Regional and International DCP reports
Meteor-M N2-2	RosHydroMet	2019-07-05	≥2024	DCS	E-S	401.9 - 402 MHz	5 kHz	RHCP	0.4 kBit/s	D	Regional DCP reports
Meteor-M N2-3	RosHydroMet	≥2023	≥2027	DA	S-E	8128 MHz	30700 kHz	LHCP	15360 kBit/s	D	Stored data
Meteor-M N2-3	RosHydroMet	≥2023	≥2027	DA	S-E	8320 MHz	30700 kHz	LHCP	15360 kBit/s	D	Stored data
Meteor-M N2-3	RosHydroMet	≥2023	≥2027	DA	S-E	8128 MHz	123000 kHz	LHCP	61440 kBit/s	D	Stored data
Meteor-M N2-3	RosHydroMet	≥2023	≥2027	DA	S-E	8320 MHz	123000 kHz	LHCP	61440 kBit/s	D	Stored data
Meteor-M N2-3	RosHydroMet	≥2023	≥2027	AHRPT	S-E	1700 MHz	3000 kHz	RHCP	3000 kBit/s	D	High resolution data + DCP reports
Meteor-M N2-3	RosHydroMet	≥2023	≥2027	AHRPT	S-E	1705 MHz	3000 kHz	RHCP	3000 kBit/s	D	High resolution data + DCP reports
Meteor-M N2-3	RosHydroMet	≥2023	≥2027	LRPT	S-E	137.1 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-3	RosHydroMet	≥2023	≥2027	LRPT	S-E	137.9 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-3	RosHydroMet	≥2023	≥2027	LRPT	S-E	137.9125 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-3	RosHydroMet	≥2023	≥2027	DCS	E-S	401.9 - 402.5 MHz	5 kHz	RHCP	1.2 kBit/s	D	Regional and International DCP reports
Meteor-M N2-3	RosHydroMet	≥2023	≥2027	DCS	E-S	401.9 - 402 MHz	5 kHz	RHCP	0.4 kBit/s	D	Regional DCP reports
Meteor-M N2-4	RosHydroMet	≥2023	≥2028	DA	S-E	8128 MHz	30700 kHz	LHCP	15360 kBit/s	D	Stored data
Meteor-M N2-4	RosHydroMet	≥2023	≥2028	DA	S-E	8320 MHz	30700 kHz	LHCP	15360 kBit/s	D	Stored data
Meteor-M N2-4	RosHydroMet	≥2023	≥2028	DA	S-E	8128 MHz	123000 kHz	LHCP	61440 kBit/s	D	Stored data
Meteor-M N2-4	RosHydroMet	≥2023	≥2028	DA	S-E	8320 MHz	123000 kHz	LHCP	61440 kBit/s	D	Stored data
Meteor-M N2-4	RosHydroMet	≥2023	≥2028	AHRPT	S-E	1700 MHz	3000 kHz	RHCP	3000 kBit/s	D	High resolution data + DCP reports
Meteor-M N2-4	RosHydroMet	≥2023	≥2028	AHRPT	S-E	1705 MHz	3000 kHz	RHCP	3000 kBit/s	D	High resolution data + DCP reports
Meteor-M N2-4	RosHydroMet	≥2023	≥2028	LRPT	S-E	137.1 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-4	RosHydroMet	≥2023	≥2028	LRPT	S-E	137.9 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-4	RosHydroMet	≥2023	≥2028	LRPT	S-E	137.9125 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-4	RosHydroMet	≥2023	≥2028	DCS	E-S	401.9 - 402.5 MHz	5 kHz	RHCP	1.2 kBit/s	D	Regional and International DCP reports
Meteor-M N2-4	RosHydroMet	≥2023	≥2028	DCS	E-S	401.9 - 402 MHz	5 kHz	RHCP	0.4 kBit/s	D	Regional DCP reports
Meteor-M N2-5	RosHydroMet	≥2024	≥2029	DA	S-E	8128 MHz	30700 kHz	LHCP	15360 kBit/s	D	Stored data
Meteor-M N2-5	RosHydroMet	≥2024	≥2029	DA	S-E	8320 MHz	30700 kHz	LHCP	15360 kBit/s	D	Stored data
Meteor-M N2-5	RosHydroMet	≥2024	≥2029	DA	S-E	8128 MHz	123000 kHz	LHCP	61440 kBit/s	D	Stored data
Meteor-M N2-5	RosHydroMet	≥2024	≥2029	DA	S-E	8320 MHz	123000 kHz	LHCP	61440 kBit/s	D	Stored data
Meteor-M N2-5	RosHydroMet	≥2024	≥2029	AHRPT	S-E	1700 MHz	3000 kHz	RHCP	3000 kBit/s	D	High resolution data + DCP reports
Meteor-M N2-5	RosHydroMet	≥2024	≥2029	AHRPT	S-E	1705 MHz	3000 kHz	RHCP	3000 kBit/s	D	High resolution data + DCP reports
Meteor-M N2-5	RosHydroMet	≥2024	≥2029	LRPT	S-E	137.1 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-5	RosHydroMet	≥2024	≥2029	LRPT	S-E	137.9 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-5	RosHydroMet	≥2024	≥2029	LRPT	S-E	137.9125 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-5	RosHydroMet	≥2024	≥2029	DCS	E-S	401.9 - 402.5 MHz	5 kHz	RHCP	1.2 kBit/s	D	Regional and International DCP reports
Meteor-M N2-5	RosHydroMet	≥2024	≥2029	DCS	E-S	401.9 - 402 MHz	5 kHz	RHCP	0.4 kBit/s	D	Regional DCP reports
Meteor-M N2-6	RosHydroMet	≥2025	≥2030	DA	S-E	8128 MHz	30700 kHz	LHCP	15360 kBit/s	D	Stored data
Meteor-M N2-6	RosHydroMet	≥2025	≥2030	DA	S-E	8320 MHz	30700 kHz	LHCP	15360 kBit/s	D	Stored data
Meteor-M N2-6	RosHydroMet	≥2025	≥2030	DA	S-E	8128 MHz	123000 kHz	LHCP	61440 kBit/s	D	Stored data
Meteor-M N2-6	RosHydroMet	≥2025	≥2030	DA	S-E	8320 MHz	123000 kHz	LHCP	61440 kBit/s	D	Stored data
Meteor-M N2-6	RosHydroMet	≥2025	≥2030	AHRPT	S-E	1700 MHz	3000 kHz	RHCP	3000 kBit/s	D	High resolution data + DCP reports
Meteor-M N2-6	RosHydroMet	≥2025	≥2030	AHRPT	S-E	1705 MHz	3000 kHz	RHCP	3000 kBit/s	D	High resolution data + DCP reports
Meteor-M N2-6	RosHydroMet	≥2025	≥2030	LRPT	S-E	137.1 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-6	RosHydroMet	≥2025	≥2030	LRPT	S-E	137.9 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-6	RosHydroMet	≥2025	≥2030	LRPT	S-E	137.9125 MHz	150 kHz	RHCP	80 kBit/s	D	Selected data
Meteor-M N2-6	RosHydroMet	≥2025	≥2030	DCS	E-S	401.9 - 402.5 MHz	5 kHz	RHCP	1.2 kBit/s	D	Regional and International DCP reports
Meteor-M N2-6	RosHydroMet	≥2025	≥2030	DCS	E-S	401.9 - 402 MHz	5 kHz	RHCP	0.4 kBit/s	D	Regional DCP reports
Meteosat-10	EUMETSAT	2012-07-05	≥2030	PGS	S-E	1686.83 MHz	5400 kHz	linear	3270 kBit/s	D	Raw data
Meteosat-10	EUMETSAT	2012-07-05	≥2030	HRIT	E-S	2105.65 MHz	2000 kHz	RHCP	1000 kBit/s	D	High resolution data - not operational
Meteosat-10	EUMETSAT	2012-07-05	≥2030	HRIT	S-E	1695.15 MHz	2000 kHz	linear	1000 kBit/s	D	High resolution data - not operational
Meteosat-10	EUMETSAT	2012-07-05	≥2030	LRIT	E-S	2101.5 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data
Meteosat-10	EUMETSAT	2012-07-05	≥2030	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data
Meteosat-10	EUMETSAT	2012-07-05	≥2030	DCS	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports, 33 channels
Meteosat-10	EUMETSAT	2012-07-05	≥2030	DCS	E-S	402.1 - 402.44 MHz	1.5 kHz	RHCP	0.100 kBit/s	D	Regional DCP reports, 223 channels
Meteosat-10	EUMETSAT	2012-07-05	≥2030	DCS	S-E	1675.281 MHz	750 kHz	linear	0.100 kBit/s	D	DCP report relay
Meteosat-11	EUMETSAT	2015-07-15	≥2033	PGS	S-E	1686.83 MHz	5400 kHz	linear	3270 kBit/s	D	Raw data
Meteosat-11	EUMETSAT	2015-07-15	≥2033	HRIT	E-S	2105.65 MHz	2000 kHz	RHCP	1000 kBit/s	D	High resolution data - not planned to be used
Meteosat-11	EUMETSAT	2015-07-15	≥2033	HRIT	S-E	1695.15 MHz	2000 kHz	linear	1000 kBit/s	D	High resolution data - not planned to be used
Meteosat-11	EUMETSAT	2015-07-15	≥2033	LRIT	E-S	2101.5 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data
Meteosat-11	EUMETSAT	2015-07-15	≥2033	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data
Meteosat-11	EUMETSAT	2015-07-15	≥2033	DCS	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports, 33 channels
Meteosat-11	EUMETSAT	2015-07-15	≥2033	DCS	E-S	402.1 - 402.44 MHz	1.5 kHz	RHCP	0.100 kBit/s	D	Regional DCP reports, 223 channels
Meteosat-11	EUMETSAT	2015-07-15	≥2033	DCS	S-E	1675.281 MHz	750 kHz	linear	0.100 kBit/s	D	DCP report relay
Meteosat-4	EUMETSAT	1989-03-06	1995-11-08	PGS	S-E	1686.83 MHz	1333.2 kHz	linear	333 kBit/s	D	Raw data
Meteosat-4	EUMETSAT	1989-03-06	1995-11-08	HRI	E-S	2105 MHz	660 kHz	RHCP	166.6 kBit/s	D	High resolution data
Meteosat-4	EUMETSAT	1989-03-06	1995-11-08	HRI	S-E	1694.5 MHz	660 kHz	linear	166.6 kBit/s	D	High resolution data
Meteosat-4	EUMETSAT	1989-03-06	1995-11-08	WEFAX	E-S	2101.5 MHz	30 kHz	RHCP	1.6 kHz	A	Selected data
Meteosat-4	EUMETSAT	1989-03-06	1995-11-08	WEFAX	S-E	1691 MHz	30 kHz	linear	1.6 kHz	A	Selected data
Meteosat-4	EUMETSAT	1989-03-06	1995-11-08	DCS	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports, 33 channels
Meteosat-4	EUMETSAT	1989-03-06	1995-11-08	DCS	E-S	402.1 - 402.2 MHz	1.5 kHz	RHCP	0.100 kBit/s	D	Regional DCP reports, 33 channels
Meteosat-4	EUMETSAT	1989-03-06	1995-11-08	DCS	S-E	1675.281 MHz	200 kHz	linear	0.100 kBit/s	D	DCP report relay
Meteosat-4	EUMETSAT	1989-03-06	1995-11-08	MDD	S-E	1695.74 MHz	120 kHz	linear	2.4 kBit/s	D	Information
Meteosat-5	EUMETSAT	1991-03-02	1998-06-01	PGS	S-E	1686.83 MHz	1333.2 kHz	linear	333 kBit/s	D	Raw data
Meteosat-5	EUMETSAT	1991-03-02	1998-06-01	HRI	E-S	2105 MHz	660 kHz	RHCP	166.6 kBit/s	D	High resolution data
Meteosat-5	EUMETSAT	1991-03-02	1998-06-01	HRI	S-E	1694.5 MHz	660 kHz	linear	166.6 kBit/s	D	High resolution data
Meteosat-5	EUMETSAT	1991-03-02	1998-06-01	WEFAX	E-S	2101.5 MHz	30 kHz	RHCP	1.6 kHz	A	Selected data
Meteosat-5	EUMETSAT	1991-03-02	1998-06-01	WEFAX	S-E	1691 MHz	30 kHz	linear	1.6 kHz	A	Selected data
Meteosat-5	EUMETSAT	1991-03-02	1998-06-01	DCS	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports, 33 channels
Meteosat-5	EUMETSAT	1991-03-02	1998-06-01	DCS	E-S	402.1 - 402.2 MHz	1.5 kHz	RHCP	0.100 kBit/s	D	Regional DCP reports, 33 channels
Meteosat-5	EUMETSAT	1991-03-02	1998-06-01	DCS	S-E	1675.281 MHz	200 kHz	linear	0.100 kBit/s	D	DCP report relay
Meteosat-5	EUMETSAT	1991-03-02	1998-06-01	MDD	S-E	1695.74 MHz	120 kHz	linear	2.4 kBit/s	D	Information
Meteosat-5 (IODC)	EUMETSAT	1998-06-01	2007-04-26	PGS	S-E	1686.83 MHz	1333.2 kHz	linear	333 kBit/s	D	Raw data
Meteosat-5 (IODC)	EUMETSAT	1998-06-01	2007-04-26	HRI	E-S	2105 MHz	660 kHz	RHCP	166.6 kBit/s	D	High resolution data
Meteosat-5 (IODC)	EUMETSAT	1998-06-01	2007-04-26	HRI	S-E	1694.5 MHz	660 kHz	linear	166.6 kBit/s	D	High resolution data
Meteosat-5 (IODC)	EUMETSAT	1998-06-01	2007-04-26	WEFAX	E-S	2101.5 MHz	30 kHz	RHCP	1.6 kHz	A	Selected data
Meteosat-5 (IODC)	EUMETSAT	1998-06-01	2007-04-26	WEFAX	S-E	1691 MHz	30 kHz	linear	1.6 kHz	A	Selected data
Meteosat-5 (IODC)	EUMETSAT	1998-06-01	2007-04-26	DCS	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports, 33 channels
Meteosat-5 (IODC)	EUMETSAT	1998-06-01	2007-04-26	DCS	E-S	402.1 - 402.2 MHz	1.5 kHz	RHCP	0.100 kBit/s	D	Regional DCP reports, 33 channels
Meteosat-5 (IODC)	EUMETSAT	1998-06-01	2007-04-26	DCS	S-E	1675.28 MHz	200 kHz	linear	0.100 kBit/s	D	DCP report relay
Meteosat-6	EUMETSAT	1993-11-20	2007-04-27	PGS	S-E	1686.83 MHz	1333.2 kHz	linear	333 kBit/s	D	Raw data
Meteosat-6	EUMETSAT	1993-11-20	2007-04-27	HRI	E-S	2105 MHz	660 kHz	RHCP	166.6 kBit/s	D	High resolution data
Meteosat-6	EUMETSAT	1993-11-20	2007-04-27	HRI	S-E	1694.5 MHz	660 kHz	linear	166.6 kBit/s	D	High resolution data
Meteosat-6	EUMETSAT	1993-11-20	2007-04-27	WEFAX	E-S	2101.5 MHz	30 kHz	RHCP	1.6 kHz	A	Selected data
Meteosat-6	EUMETSAT	1993-11-20	2007-04-27	WEFAX	S-E	1691 MHz	30 kHz	linear	1.6 kHz	A	Selected data
Meteosat-6	EUMETSAT	1993-11-20	2007-04-27	DCS	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports, 33 channels
Meteosat-6	EUMETSAT	1993-11-20	2007-04-27	DCS	E-S	402.1 - 402.2 MHz	1.5 kHz	RHCP	0.100 kBit/s	D	Regional DCP reports, 33 channels
Meteosat-6	EUMETSAT	1993-11-20	2007-04-27	DCS	S-E	1675.281 MHz	200 kHz	linear	0.100 kBit/s	D	DCP report relay
Meteosat-6	EUMETSAT	1993-11-20	2007-04-27	MDD	S-E	1695.74 MHz	120 kHz	linear	2.4 kBit/s	D	Information
Meteosat-6 (IODC)	EUMETSAT	2007-04-27	2011-04-15	PGS	S-E	1686.83 MHz	1333.2 kHz	linear	333 kBit/s	D	Raw data
Meteosat-6 (IODC)	EUMETSAT	2007-04-27	2011-04-15	HRI	E-S	2105 MHz	660 kHz	RHCP	166.6 kBit/s	D	High resolution data
Meteosat-6 (IODC)	EUMETSAT	2007-04-27	2011-04-15	HRI	S-E	1694.5 MHz	660 kHz	linear	166.6 kBit/s	D	High resolution data
Meteosat-6 (IODC)	EUMETSAT	2007-04-27	2011-04-15	WEFAX	E-S	2101.5 MHz	30 kHz	RHCP	1.6 kHz	A	Selected data
Meteosat-6 (IODC)	EUMETSAT	2007-04-27	2011-04-15	WEFAX	S-E	1691 MHz	30 kHz	linear	1.6 kHz	A	Selected data
Meteosat-6 (IODC)	EUMETSAT	2007-04-27	2011-04-15	DCS	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports, 33 channels
Meteosat-6 (IODC)	EUMETSAT	2007-04-27	2011-04-15	DCS	E-S	402.1 - 402.2 MHz	1.5 kHz	RHCP	0.100 kBit/s	D	Regional DCP reports, 33 channels
Meteosat-6 (IODC)	EUMETSAT	2007-04-27	2011-04-15	DCS	S-E	1675.281 MHz	200 kHz	linear	0.100 kBit/s	D	DCP report relay
Meteosat-7	EUMETSAT	1997-09-02	2006-12-05	PGS	S-E	1686.83 MHz	1333.2 kHz	linear	333 kBit/s	D	Raw data
Meteosat-7	EUMETSAT	1997-09-02	2006-12-05	HRI	E-S	2105 MHz	660 kHz	RHCP	166.6 kBit/s	D	High resolution data
Meteosat-7	EUMETSAT	1997-09-02	2006-12-05	HRI	S-E	1694.5 MHz	660 kHz	linear	166.6 kBit/s	D	High resolution data
Meteosat-7	EUMETSAT	1997-09-02	2006-12-05	WEFAX	E-S	2101.5 MHz	30 kHz	RHCP	1.6 kHz	A	Selected data
Meteosat-7	EUMETSAT	1997-09-02	2006-12-05	WEFAX	S-E	1691 MHz	30 kHz	linear	1.6 kHz	A	Selected data
Meteosat-7	EUMETSAT	1997-09-02	2006-12-05	DCS	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports, 33 channels
Meteosat-7	EUMETSAT	1997-09-02	2006-12-05	DCS	E-S	402.1 - 402.2 MHz	1.5 kHz	RHCP	0.100 kBit/s	D	Regional DCP reports, 33 channels
Meteosat-7	EUMETSAT	1997-09-02	2006-12-05	DCS	S-E	1675.281 MHz	200 kHz	linear	0.100 kBit/s	D	DCP report relay
Meteosat-7	EUMETSAT	1997-09-02	2006-12-05	MDD	S-E	1695.74 MHz	120 kHz	linear	2.4 kBit/s	D	Information
Meteosat-7 (IODC)	EUMETSAT	2006-12-05	2017-02-01	PGS	S-E	1686.83 MHz	1333.2 kHz	linear	333 kBit/s	D	Raw data
Meteosat-7 (IODC)	EUMETSAT	2006-12-05	2017-02-01	HRI	E-S	2105 MHz	660 kHz	RHCP	166.6 kBit/s	D	High resolution data
Meteosat-7 (IODC)	EUMETSAT	2006-12-05	2017-02-01	HRI	S-E	1694.5 MHz	660 kHz	linear	166.6 kBit/s	D	High resolution data
Meteosat-7 (IODC)	EUMETSAT	2006-12-05	2017-02-01	WEFAX	E-S	2101.5 MHz	30 kHz	RHCP	1.6 kHz	A	Selected data
Meteosat-7 (IODC)	EUMETSAT	2006-12-05	2017-02-01	WEFAX	S-E	1691 MHz	30 kHz	linear	1.6 kHz	A	Selected data
Meteosat-7 (IODC)	EUMETSAT	2006-12-05	2017-02-01	DCS	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports, 33 channels
Meteosat-7 (IODC)	EUMETSAT	2006-12-05	2017-02-01	DCS	E-S	402.1 - 402.2 MHz	1.5 kHz	RHCP	0.100 kBit/s	D	Regional DCP reports, 33 channels
Meteosat-7 (IODC)	EUMETSAT	2006-12-05	2017-02-01	DCS	S-E	1675.281 MHz	200 kHz	linear	0.100 kBit/s	D	DCP report relay
Meteosat-7 (IODC)	EUMETSAT	2006-12-05	2017-02-01	MDD	S-E	1695.74 MHz	120 kHz	linear	2.4 kBit/s	D	Information
Meteosat-8	EUMETSAT	2002-08-28	2016-07-04	PGS	S-E	1686.83 MHz	5400 kHz	linear	3270 kBit/s	D	Raw data
Meteosat-8	EUMETSAT	2002-08-28	2016-07-04	HRIT	E-S	2105.65 MHz	2000 kHz	RHCP	1000 kBit/s	D	High resolution data - not in use
Meteosat-8	EUMETSAT	2002-08-28	2016-07-04	HRIT	S-E	1695.15 MHz	2000 kHz	linear	1000 kBit/s	D	High resolution data - not in use
Meteosat-8	EUMETSAT	2002-08-28	2016-07-04	LRIT	E-S	2101.5 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data - not in use
Meteosat-8	EUMETSAT	2002-08-28	2016-07-04	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data - not in use
Meteosat-8	EUMETSAT	2002-08-28	2016-07-04	DCS	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports, 33 channels
Meteosat-8	EUMETSAT	2002-08-28	2016-07-04	DCS	E-S	402.1 - 402.44 MHz	1.5 kHz	RHCP	0.100 kBit/s	D	Regional DCP reports, 223 channels
Meteosat-8	EUMETSAT	2002-08-28	2016-07-04	DCS	S-E	1675.281 MHz	750 kHz	linear	0.100 kBit/s	D	DCP report relay
Meteosat-8 (IODC)	EUMETSAT	2016-09-15	≥2022-11	PGS	S-E	1686.83 MHz	5400 kHz	linear	3270 kBit/s	D	Raw data
Meteosat-8 (IODC)	EUMETSAT	2016-09-15	≥2022-11	HRIT	E-S	2105.65 MHz	2000 kHz	RHCP	1000 kBit/s	D	High resolution data - not in use
Meteosat-8 (IODC)	EUMETSAT	2016-09-15	≥2022-11	HRIT	S-E	1695.15 MHz	2000 kHz	linear	1000 kBit/s	D	High resolution data - not in use
Meteosat-8 (IODC)	EUMETSAT	2016-09-15	≥2022-11	LRIT	E-S	2101.5 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data - not in use
Meteosat-8 (IODC)	EUMETSAT	2016-09-15	≥2022-11	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data - not in use
Meteosat-8 (IODC)	EUMETSAT	2016-09-15	≥2022-11	DCS	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports, 33 channels
Meteosat-8 (IODC)	EUMETSAT	2016-09-15	≥2022-11	DCS	E-S	402.1 - 402.44 MHz	1.5 kHz	RHCP	0.100 kBit/s	D	Regional DCP reports, 223 channels
Meteosat-8 (IODC)	EUMETSAT	2016-09-15	≥2022-11	DCS	S-E	1675.281 MHz	750 kHz	linear	0.100 kBit/s	D	DCP report relay
Meteosat-9	EUMETSAT	2005-12-21	2022-04-01	PGS	S-E	1686.83 MHz	5400 kHz	linear	3270 kBit/s	D	Raw data
Meteosat-9	EUMETSAT	2005-12-21	2022-04-01	HRIT	E-S	2105.65 MHz	2000 kHz	RHCP	1000 kBit/s	D	High resolution data - not in use
Meteosat-9	EUMETSAT	2005-12-21	2022-04-01	HRIT	S-E	1695.15 MHz	2000 kHz	linear	1000 kBit/s	D	High resolution data - not in use
Meteosat-9	EUMETSAT	2005-12-21	2022-04-01	LRIT	E-S	2101.5 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data
Meteosat-9	EUMETSAT	2005-12-21	2022-04-01	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data
Meteosat-9	EUMETSAT	2005-12-21	2022-04-01	DCS (international)	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports, 33 channels
Meteosat-9	EUMETSAT	2005-12-21	2022-04-01	DCS (regional)	E-S	402.1 - 402.44 MHz	1.5 kHz	RHCP	0.100 kBit/s	D	Regional DCP reports, 223 channels
Meteosat-9	EUMETSAT	2005-12-21	2022-04-01	DCS	S-E	1675.281 MHz	750 kHz	linear	0.100 kBit/s	D	DCP report relay
Meteosat-9 (IODC)	EUMETSAT	2022-07-01	≥2025	PGS	S-E	1686.83 MHz	5400 kHz	linear	3270 kBit/s	D	Raw data
Meteosat-9 (IODC)	EUMETSAT	2022-07-01	≥2025	HRIT	E-S	2105.65 MHz	2000 kHz	RHCP	1000 kBit/s	D	High resolution data - not in use
Meteosat-9 (IODC)	EUMETSAT	2022-07-01	≥2025	HRIT	S-E	1695.15 MHz	2000 kHz	linear	1000 kBit/s	D	High resolution data - not in use
Meteosat-9 (IODC)	EUMETSAT	2022-07-01	≥2025	LRIT	E-S	2101.5 MHz	660 kHz	RHCP	128 kBit/s	D	Selected data
Meteosat-9 (IODC)	EUMETSAT	2022-07-01	≥2025	LRIT	S-E	1691 MHz	660 kHz	linear	128 kBit/s	D	Selected data
Meteosat-9 (IODC)	EUMETSAT	2022-07-01	≥2025	DCS (international)	E-S	402 - 402.1 MHz	3 kHz	RHCP	0.100 kBit/s	D	International DCP reports, 33 channels
Meteosat-9 (IODC)	EUMETSAT	2022-07-01	≥2025	DCS (regional)	E-S	402.1 - 402.44 MHz	1.5 kHz	RHCP	0.100 kBit/s	D	Regional DCP reports, 223 channels
Meteosat-9 (IODC)	EUMETSAT	2022-07-01	≥2025	DCS	S-E	1675.281 MHz	750 kHz	linear	0.100 kBit/s	D	DCP report relay
Metop-A	EUMETSAT	2006-10-19	2021-11-15	GDS	S-E	7800 MHz	63000 kHz	RHCP	70000 kBit/s	D	Raw data
Metop-A	EUMETSAT	2006-10-19	2021-11-15	AHRPT	S-E	1701.3 MHz	4500 kHz	RHCP	3500 kBit/s	D	High resolution data - not in use
Metop-A	EUMETSAT	2006-10-19	2021-11-15	AHRPT	S-E	1707 MHz	4500 kHz	RHCP	3500 kBit/s	D	High resolution data - used part time
Metop-A	EUMETSAT	2006-10-19	2021-11-15	LRPT	S-E	137.1 MHz	150 kHz	RHCP	72 kBit/s	D	Selected data - not in use
Metop-A	EUMETSAT	2006-10-19	2021-11-15	LRPT	S-E	137.9125 MHz	150 kHz	RHCP	72 kBit/s	D	Selected data - backup, not in use
Metop-A	EUMETSAT	2006-10-19	2021-11-15	ADCS	E-S	401.585 MHz	10 kHz	RHCP	0.4/4.8 kBit/s	D	DCP reports
Metop-A	EUMETSAT	2006-10-19	2021-11-15	ADCS	S-E	465.9875 MHz	1 kHz	RHCP	0.2/0.4 kBit/s	D	DCP configuration control
Metop-B	EUMETSAT	2012-09-17	≥2024	GDS	S-E	7800 MHz	63000 kHz	RHCP	70000 kBit/s	D	Raw data
Metop-B	EUMETSAT	2012-09-17	≥2024	AHRPT	S-E	1701.3 MHz	4500 kHz	RHCP	3500 kBit/s	D	High resolution data
Metop-B	EUMETSAT	2012-09-17	≥2024	AHRPT	S-E	1707 MHz	4500 kHz	RHCP	3500 kBit/s	D	High resolution data - backup
Metop-B	EUMETSAT	2012-09-17	≥2024	LRPT	S-E	137.1 MHz	150 kHz	RHCP	72 kBit/s	D	Selected data
Metop-B	EUMETSAT	2012-09-17	≥2024	LRPT	S-E	137.9125 MHz	150 kHz	RHCP	72 kBit/s	D	Selected data - backup
Metop-B	EUMETSAT	2012-09-17	≥2024	ADCS	E-S	401.595 MHz	10 kHz	RHCP	0.4/4.8 kBit/s	D	DCP reports
Metop-B	EUMETSAT	2012-09-17	≥2024	ADCS	S-E	465.9875 MHz	1 kHz	RHCP	0.2/0.4 kBit/s	D	DCP configuration control
Metop-C	EUMETSAT	2018-11-07	≥2027	GDS	S-E	7800 MHz	63000 kHz	RHCP	70000 kBit/s	D	Raw data
Metop-C	EUMETSAT	2018-11-07	≥2027	AHRPT	S-E	1701.3 MHz	4500 kHz	RHCP	3500 kBit/s	D	High resolution data - not in use
Metop-C	EUMETSAT	2018-11-07	≥2027	AHRPT	S-E	1707 MHz	4500 kHz	RHCP	3500 kBit/s	D	High resolution data - used part time
Metop-C	EUMETSAT	2018-11-07	≥2027	LRPT	S-E	137.1 MHz	150 kHz	RHCP	72 kBit/s	D	Selected data - not in use
Metop-C	EUMETSAT	2018-11-07	≥2027	LRPT	S-E	137.9125 MHz	150 kHz	RHCP	72 kBit/s	D	Selected data - backup, not in use
Metop-C	EUMETSAT	2018-11-07	≥2027	ADCS	E-S	401.585 MHz	10 kHz	RHCP	0.4/4.8 kBit/s	D	DCP reports
Metop-C	EUMETSAT	2018-11-07	≥2027	ADCS	S-E	465.9875 MHz	1 kHz	RHCP	0.2/0.4 kBit/s	D	DCP configuration control
Metop-SG-A1	EUMETSAT	≥2024	≥2031	DDB	S-E	7825 MHz	150000 kHz	RHCP	80000/186600 kBit/s	D	Direct Data Broadcast
Metop-SG-A1	EUMETSAT	≥2024	≥2031	SMD	S-E	26295 MHz	366000 kHz	RHCP	390500/455500 kBit/s	D	Stored Mission Data, Channel 1
Metop-SG-A1	EUMETSAT	≥2024	≥2031	SMD	S-E	26700 MHz	366000 kHz	RHCP	390500/455500 kBit/s	D	Stored Mission Data, Channel 2
Metop-SG-A1	EUMETSAT	≥2024	≥2031	ADCS	E-S	401 - 401.6900000000001 MHz	80 kHz	RHCP	4.8/9.6 kBit/s	D	Argos DCS
Metop-SG-A1	EUMETSAT	≥2024	≥2031	ADCS	S-E	465.9875 MHz	20 kHz	RHCP	0.97751/1000 kBit/s	D	Argos DCS return link
Metop-SG-A2	EUMETSAT	≥2031	≥2038	DDB	S-E	7825 MHz	150000 kHz	RHCP	80000/186600 kBit/s	D	Direct Data Broadcast
Metop-SG-A2	EUMETSAT	≥2031	≥2038	SMD	S-E	26295 MHz	366000 kHz	RHCP	390500/455500 kBit/s	D	Stored Mission Data, Channel 1
Metop-SG-A2	EUMETSAT	≥2031	≥2038	SMD	S-E	26700 MHz	366000 kHz	RHCP	390500/455500 kBit/s	D	Stored Mission Data, Channel 2
Metop-SG-A2	EUMETSAT	≥2031	≥2038	ADCS	E-S	401 - 401.6900000000001 MHz	80 kHz	RHCP	4.8/9.6 kBit/s	D	Argos DCS
Metop-SG-A2	EUMETSAT	≥2031	≥2038	ADCS	S-E	465.9875 MHz	20 kHz	RHCP	0.97751/1000 kBit/s	D	Argos DCS return link
Metop-SG-A3	EUMETSAT	≥2038	≥2045	DDB	S-E	7825 MHz	150000 kHz	RHCP	80000/186600 kBit/s	D	Direct Data Broadcast
Metop-SG-A3	EUMETSAT	≥2038	≥2045	SMD	S-E	26295 MHz	366000 kHz	RHCP	390500/455500 kBit/s	D	Stored Mission Data, Channel 1
Metop-SG-A3	EUMETSAT	≥2038	≥2045	SMD	S-E	26700 MHz	366000 kHz	RHCP	390500/455500 kBit/s	D	Stored Mission Data, Channel 2
Metop-SG-A3	EUMETSAT	≥2038	≥2045	ADCS	E-S	401 - 401.6900000000001 MHz	80 kHz	RHCP	4.8/9.6 kBit/s	D	Argos DCS
Metop-SG-A3	EUMETSAT	≥2038	≥2045	ADCS	S-E	465.9875 MHz	20 kHz	RHCP	0.97751/1000 kBit/s	D	Argos DCS return link
Metop-SG-B1	EUMETSAT	≥2025	≥2032	DDB	S-E	7825 MHz	150000 kHz	RHCP	80000/186600 kBit/s	D	Direct Data Broadcast
Metop-SG-B1	EUMETSAT	≥2025	≥2032	SMD	S-E	26700 MHz	366000 kHz	RHCP	390500/455500 kBit/s	D	Stored Mission Data
Metop-SG-B1	EUMETSAT	≥2025	≥2032	ADCS	E-S	401 - 401.6900000000001 MHz	80 kHz	RHCP	4.8/9.6 kBit/s	D	Argos DCS
Metop-SG-B1	EUMETSAT	≥2025	≥2032	ADCS	S-E	465.9875 MHz	20 kHz	RHCP	0.97751/1000 kBit/s	D	Argos DCS return link
Metop-SG-B2	EUMETSAT	≥2032	≥2039	DDB	S-E	7825 MHz	150000 kHz	RHCP	80000/186600 kBit/s	D	Direct Data Broadcast
Metop-SG-B2	EUMETSAT	≥2032	≥2039	SMD	S-E	26700 MHz	366000 kHz	RHCP	390500/455500 kBit/s	D	Stored Mission Data
Metop-SG-B2	EUMETSAT	≥2032	≥2039	ADCS	E-S	401 - 401.6900000000001 MHz	80 kHz	RHCP	4.8/9.6 kBit/s	D	Argos DCS
Metop-SG-B2	EUMETSAT	≥2032	≥2039	ADCS	S-E	465.9875 MHz	20 kHz	RHCP	0.97751/1000 kBit/s	D	Argos DCS return link
Metop-SG-B3	EUMETSAT	≥2039	≥2046	DDB	S-E	7825 MHz	150000 kHz	RHCP	80000/186600 kBit/s	D	Direct Data Broadcast
Metop-SG-B3	EUMETSAT	≥2039	≥2046	SMD	S-E	26700 MHz	366000 kHz	RHCP	390500/455500 kBit/s	D	Stored Mission Data
Metop-SG-B3	EUMETSAT	≥2039	≥2046	ADCS	E-S	401 - 401.6900000000001 MHz	80 kHz	RHCP	4.8/9.6 kBit/s	D	Argos DCS
Metop-SG-B3	EUMETSAT	≥2039	≥2046	ADCS	S-E	465.9875 MHz	20 kHz	RHCP	0.97751/1000 kBit/s	D	Argos DCS return link
MTG-I1	EUMETSAT	≥2022-12	≥2030	MDA	S-E	26360 MHz	287000 kHz	RHCP&LHCP	165000 kBit/s	D	Mission Data Acquisition
MTG-I1	EUMETSAT	≥2022-12	≥2030	DCS	E-S	401.7 - 402.85 MHz	3 kHz	RHCP	0.1/1.5 kBit/s	D	Data Collection Platform transmissions
MTG-I1	EUMETSAT	≥2022-12	≥2030	DCS	E-S	401.7 - 402.85 MHz	1.5 kHz	RHCP	0.1/1.5 kBit/s	D	Data Collection Platform transmissions
MTG-I2	EUMETSAT	≥2025	≥2033	MDA	S-E	26360 MHz	287000 kHz	RHCP&LHCP	165000 kBit/s	D	Mission Data Acquisition
MTG-I2	EUMETSAT	≥2025	≥2033	DCS	E-S	401.7 - 402.85 MHz	3 kHz	RHCP	0.1/1.5 kBit/s	D	Data Collection Platform transmissions
MTG-I2	EUMETSAT	≥2025	≥2033	DCS	E-S	401.7 - 402.85 MHz	1.5 kHz	RHCP	0.1/1.5 kBit/s	D	Data Collection Platform transmissions
MTG-I3	EUMETSAT	≥2032	≥2040	MDA	S-E	26360 MHz	287000 kHz	RHCP&LHCP	165000 kBit/s	D	Mission Data Acquisition
MTG-I3	EUMETSAT	≥2032	≥2040	DCS	E-S	402.275 MHz	3 kHz	RHCP	0.1/1.5 kBit/s	D	Data Collection Platform transmissions
MTG-I3	EUMETSAT	≥2032	≥2040	DCS	E-S	402.275 MHz	1.5 kHz	RHCP	0.1/1.5 kBit/s	D	Data Collection Platform transmissions
MTG-I4	EUMETSAT	≥2036	≥2044	MDA	S-E	26360 MHz	287000 kHz	RHCP&LHCP	165000 kBit/s	D	Mission Data Acquisition
MTG-I4	EUMETSAT	≥2036	≥2044	DCS	E-S	401.7 - 402.85 MHz	3 kHz	RHCP	0.1/1.5 kBit/s	D	Data Collection Platform transmissions
MTG-I4	EUMETSAT	≥2036	≥2044	DCS	E-S	401.7 - 402.85 MHz	1.5 kHz	RHCP	0.1/1.5 kBit/s	D	Data Collection Platform transmissions
MTG-S1	EUMETSAT	≥2024	≥2032	MDA	S-E	26760 MHz	452000 kHz	RHCP&LHCP	260000 kBit/s	D	Mission Data Acquisition
MTG-S2	EUMETSAT	≥2034	≥2042	MDA	S-E	26760 MHz	452000 kHz	RHCP&LHCP	260000 kBit/s	D	Mission Data Acquisition
NOAA-15	NOAA	1998-05-13	≥2024	CDA	S-E	2247.5 MHz	4000 kHz	RHCP	2660 kBit/s	D	Global and Local data (GAC and LAC)
NOAA-15	NOAA	1998-05-13	≥2024	HRPT	S-E	1702.5 MHz	4000 kHz	LHCP	665 kBit/s	D	Full information data
NOAA-15	NOAA	1998-05-13	≥2024	HRPT	S-E	1698 MHz	4000 kHz	RHCP	665 kBit/s	D	Full information data
NOAA-15	NOAA	1998-05-13	≥2024	HRPT	S-E	1707 MHz	4000 kHz	RHCP	665 kBit/s	D	Full information data
NOAA-15	NOAA	1998-05-13	≥2024	APT	S-E	137.5 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-15	NOAA	1998-05-13	≥2024	APT	S-E	137.62 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-15	NOAA	1998-05-13	≥2024	APT	S-E	137.1 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-15	NOAA	1998-05-13	≥2024	APT	S-E	137.9125 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-15	NOAA	1998-05-13	≥2024	DSB	S-E	137.35 MHz	46 kHz	RHCP	8.32 kBit/s	D	TIP data
NOAA-15	NOAA	1998-05-13	≥2024	DSB	S-E	137.77 MHz	46 kHz	RHCP	8.32 kBit/s	D	TIP data
NOAA-16	NOAA	2000-09-21	2014-06-09	CDA	S-E	2247.5 MHz	4000 kHz	RHCP	2660 kBit/s	D	Global and Local data (GAC and LAC)
NOAA-16	NOAA	2000-09-21	2014-06-09	HRPT	S-E	1702.5 MHz	4000 kHz	LHCP	665 kBit/s	D	Full information data
NOAA-16	NOAA	2000-09-21	2014-06-09	HRPT	S-E	1698 MHz	4000 kHz	RHCP	665 kBit/s	D	Full information data
NOAA-16	NOAA	2000-09-21	2014-06-09	HRPT	S-E	1707 MHz	4000 kHz	RHCP	665 kBit/s	D	Full information data
NOAA-16	NOAA	2000-09-21	2014-06-09	APT	S-E	137.35 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-16	NOAA	2000-09-21	2014-06-09	APT	S-E	137.77 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-16	NOAA	2000-09-21	2014-06-09	APT	S-E	137.1 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-16	NOAA	2000-09-21	2014-06-09	APT	S-E	137.9125 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-16	NOAA	2000-09-21	2014-06-09	DSB	S-E	137.35 MHz	46 kHz	RHCP	8.32 kBit/s	D	TIP data
NOAA-16	NOAA	2000-09-21	2014-06-09	DSB	S-E	137.77 MHz	46 kHz	RHCP	8.32 kBit/s	D	TIP data
NOAA-17	NOAA	2002-06-24	2013-04-10	CDA	S-E	2247.5 MHz	2000 kHz	RHCP	2660 kBit/s	D	Global and Local data (GAC and LAC)
NOAA-17	NOAA	2002-06-24	2013-04-10	HRPT	S-E	1702.5 MHz	4000 kHz	LHCP	665 kBit/s	D	Full information data
NOAA-17	NOAA	2002-06-24	2013-04-10	HRPT	S-E	1698 MHz	4000 kHz	RHCP	665 kBit/s	D	Full information data
NOAA-17	NOAA	2002-06-24	2013-04-10	HRPT	S-E	1707 MHz	4000 kHz	RHCP	665 kBit/s	D	Full information data
NOAA-17	NOAA	2002-06-24	2013-04-10	APT	S-E	137.5 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-17	NOAA	2002-06-24	2013-04-10	APT	S-E	137.62 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-17	NOAA	2002-06-24	2013-04-10	APT	S-E	137.1 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-17	NOAA	2002-06-24	2013-04-10	APT	S-E	137.9125 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-17	NOAA	2002-06-24	2013-04-10	DSB	S-E	137.35 MHz	46 kHz	RHCP	8.32 kBit/s	D	TIP data
NOAA-17	NOAA	2002-06-24	2013-04-10	DSB	S-E	137.77 MHz	46 kHz	RHCP	8.32 kBit/s	D	TIP data
NOAA-18	NOAA	2005-05-20	≥2024	CDA	S-E	2247.5 MHz	4000 kHz	RHCP	2660 kBit/s	D	Global and Local data (GAC and LAC)
NOAA-18	NOAA	2005-05-20	≥2024	HRPT	S-E	1702.5 MHz	4000 kHz	LHCP	665 kBit/s	D	Full information data
NOAA-18	NOAA	2005-05-20	≥2024	HRPT	S-E	1698 MHz	4000 kHz	RHCP	665 kBit/s	D	Full information data
NOAA-18	NOAA	2005-05-20	≥2024	HRPT	S-E	1707 MHz	4000 kHz	RHCP	665 kBit/s	D	Full information data
NOAA-18	NOAA	2005-05-20	≥2024	APT	S-E	137.35 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-18	NOAA	2005-05-20	≥2024	APT	S-E	137.77 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-18	NOAA	2005-05-20	≥2024	APT	S-E	137.1 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-18	NOAA	2005-05-20	≥2024	APT	S-E	137.9125 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-18	NOAA	2005-05-20	≥2024	DSB	S-E	137.35 MHz	46 kHz	RHCP	8.32 kBit/s	D	TIP data
NOAA-18	NOAA	2005-05-20	≥2024	DSB	S-E	137.77 MHz	46 kHz	RHCP	8.32 kBit/s	D	TIP data
NOAA-19	NOAA	2009-02-06	≥2024	CDA	S-E	2247.5 MHz	2000 kHz	RHCP	2660 kBit/s	D	Global and Local data (GAC and LAC)
NOAA-19	NOAA	2009-02-06	≥2024	HRPT	S-E	1702.5 MHz	4000 kHz	LHCP	665 kBit/s	D	Full information data
NOAA-19	NOAA	2009-02-06	≥2024	HRPT	S-E	1698 MHz	4000 kHz	RHCP	665 kBit/s	D	Full information data
NOAA-19	NOAA	2009-02-06	≥2024	HRPT	S-E	1707 MHz	4000 kHz	RHCP	665 kBit/s	D	Full information data
NOAA-19	NOAA	2009-02-06	≥2024	APT	S-E	137.35 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-19	NOAA	2009-02-06	≥2024	APT	S-E	137.77 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-19	NOAA	2009-02-06	≥2024	APT	S-E	137.1 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-19	NOAA	2009-02-06	≥2024	APT	S-E	137.9125 MHz	38 kHz	RHCP	1.7 kHz	A	Reduced resolution images
NOAA-19	NOAA	2009-02-06	≥2024	DSB	S-E	137.35 MHz	46 kHz	RHCP	8.32 kBit/s	D	TIP data
NOAA-19	NOAA	2009-02-06	≥2024	DSB	S-E	137.77 MHz	46 kHz	RHCP	8.32 kBit/s	D	TIP data
NOAA-20	NOAA	2017-11-18	≥2024	SMD	S-E	26703.4 MHz	300000 kHz	RHCP	300000 kBit/s	D	Stored Mission Data
NOAA-20	NOAA	2017-11-18	≥2024	HRD	S-E	7812 MHz	30000 kHz	RHCP	30000 kBit/s	D	Real-time High Rate Data
NOAA-21	NOAA	2022-11-10	≥2030	SMD	S-E	26703.4 MHz	300000 kHz	RHCP	300000 kBit/s	D	Stored Mission Data
NOAA-21	NOAA	2022-11-10	≥2030	HRD	S-E	7812 MHz	30000 kHz	RHCP	30000 kBit/s	D	Real-time High Rate Data
RCM-1	CSA	2019-06-12	≥2026	SAR RCM	active	5400 - 5400 MHz	N/R kHz	-		A	C-band SAR
Sentinel-3A	ESA	2016-02-16	≥2023	Raw Data	S-E	8095 MHz	140000 kHz	RHCP	260000/280000 kBit/s	D	Raw data downlink
Sentinel-3A	ESA	2016-02-16	≥2023	Raw Data	S-E	8260 MHz	140000 kHz	RHCP	260000/280000 kBit/s	D	Raw data downlink
Sentinel-3B	ESA	2018-04-25	≥2025	Raw Data	S-E	8095 MHz	140000 kHz	RHCP	260000/280000 kBit/s	D	Raw data downlink
Sentinel-3B	ESA	2018-04-25	≥2025	Raw Data	S-E	8260 MHz	140000 kHz	RHCP	260000/280000 kBit/s	D	Raw data downlink
Sentinel-3C	ESA	≥2024	≥2031	Raw Data	S-E	8095 MHz	140000 kHz	RHCP	260000/280000 kBit/s	D	Raw data downlink
Sentinel-3C	ESA	≥2024	≥2031	Raw Data	S-E	8260 MHz	140000 kHz	RHCP	260000/280000  kBit/s	D	Raw data downlink
Sentinel-3D	ESA	≥2028	≥2035	Raw Data	S-E	8095 MHz	140000 kHz	RHCP	260000/280000 kBit/s	D	Raw data downlink
Sentinel-3D	ESA	≥2028	≥2035	Raw Data	S-E	8260 MHz	140000 kHz	RHCP	260000/280000 kBit/s	D	Raw data downlink
Sentinel-6A	EUMETSAT	2020-11-21	≥2027	XDD	S-E	8090 MHz	120000 kHz	RHCP&LHCP	150000 kBit/s	D	Data Downlink
Sentinel-6B	EUMETSAT	≥2025	≥2032	XDD	S-E	8090 MHz	120000 kHz	RHCP	150000 kBit/s	D	Data Downlink
SNPP	NOAA	2011-10-28	≥2023	SMD	S-E	8212.5 MHz	300000 kHz	RHCP	262000 kBit/s	D	Stored Mission Data
SNPP	NOAA	2011-10-28	≥2023	HRD	S-E	7812 MHz	30000 kHz	RHCP	13000 kBit/s	D	Real-time High Rate Data
THEOS-1	GISTDA	2008-10-01	≥2025	IMAGER	S-E	8080 - 8200 MHz	kHz	RHCP	120000 kBit/s	D	Earth Observation Image Data (PAN/MS)
THEOS-2 Main	GISTDA	≥2023-02	≥2026	IMAGER	S-E	8150 MHz	250000 kHz	-	620000 kHz	A	Earth Observation Image Data (PAN/MS)
THEOS-2 Small	GISTDA	≥2023-03	≥2033	IMAGER	S-E	8200 MHz	130000 kHz	LHCP	160000 kBit/s	D	Earth Observation RGB Image data

This does NOT include telemetry and command information which is controlled under the International Traffic in Arms Regulations (ITAR) by the U.S. Department of State and other foreign signatories.
